Converting The Carrier And Harness From Right Hip Mount To Left Hip Mount (Bag Carrier) - MSA PremAire Cadet Escape G1 Operating Manual

9.2

Converting the Carrier and Harness from Right Hip Mount to Left Hip Mount (Bag Carrier)

NOTE: The PremAire Cadet Escape Respirator is designed for use with the cylinder located on the
right hip. The respirator will be most comfortable for most users in this configuration.
(1) As necessary, disconnect the attachment hose from the air supply
hose.
(2) Disconnect the strain relief strap from the shoulder strap snap
hook (strap with buckle).
(3) Disconnect the cylinder carrier from the shoulder strap and pull
strap (strap without buckle).
(4) Rotate the bag 180 ° so that the gauge face is opposite the bag
logo.
(5) Unweave the waist belt strap from the male waist belt buckle.
(6) Unweave the waist belt from the shoulder strap and pull strap.
