3.3

Inlet Pressure Gauge

To ensure accurate pressure readings, the inlet pressure gauge must be located at the air source.
3.4

Supply Hose-to-Supply Hose Connections

Use MSA-approved couplings only for supply hose connections.
Hoses must only be interconnected with either the threaded connector (3/4-16 UNF) or locking
quick-disconnect couplings listed below. DO NOT use non-locking quick disconnects to interconnect
air supply hoses.
CEJN - Chrome
SNAP-TITE — Aluminum
SNAP-TITE — Stainless Steel
Locking quick-disconnects connect by pushing the plug and socket together. To separate, push the
plug and socket together, then pull the socket sleeve away from the plug.
3.5

Supply Hose-to-Attachment Hose Connections

Attachment hose connections are to be made through approved MSA couplings only.
CAUTION
