a. Power
Press the power button to turn on the camera . If the position preset 0 has been stored, the position preset 0
will be called after initialization . Press the power button again to turn the camera off, it will turn to the back
when turned off, this is called the "privacy mode" .
b. Set
This button has no function with this camera .
c. Camera select
Up to 4 different cameras can be controlled with 1 IR remote Control . With the camera select buttons [1,2,3,4]
you can select the IR channel the remote control is using . The default camera IR channel is 1 .
To control a camera on first use, please select camera 1 (IR channel 1) on the remote control . To control a
second camera you first need to change the IR channel stored in the camera from 1 to 2 .
• First turn off the other camera's in the room you don't want to change, to prevent
that other camera's also get changed accidentally .
• Select camera 1 on the remote control, because the camera is still configured to
listen to IR channel 1 .
• Press [*]+[#]+[F2] to change the IR channel inside the camera to IR channel 2 .
The camera will confirm this on screen .
• Select camera 2 on the remote control to control this camera .
Key Combinations: (Default IR address is 1)
[*]+[#]+[F1] : Camera Address No . 1 [*]+[#]+[F3]
[*]+[#]+[F2] : Camera Address No . 2 [*]+[#]+[F4]
d. Number Keys
The number keys are used to call presets . Press the number [0-9] of the preset desired and the camera will
respond accordingly (See 'h' on how to set & clear presets)
e. Focus + -
Push the button [manual focus] first before using the focus buttons . Focus the camera with the [+] and [–]
button . If the camera does not respond check if the camera is set to auto-focus .
f. Auto/Manual Focus
Set the camera in auto-focus or manual-focus . If the camera is configured to auto-focus the buttons [Focus
+ -] are disabled . When the camera is in "manual focus" modus and the Zoom buttons are used, the camera
automatically switces to auto-focus .
g. Zoom + -
Zoom the camera with these buttons . When the camera is in "manual focus" modus and the Zoom buttons
are used, the camera automatically switches to auto-focus .
h. Set & Clear Preset
A preset is a specific position of a camera that you save into the camera . A preset is assigned to a number
from 0-9 . To set a preset first point the camera in a specific directing and a specific zoom position . Now as-
sign the position to a number with the button "Set Preset" . You can call the preset by pressing the number 0-9
on the remote control .
Set Preset:
Call Preset:
Clear Preset:
If the position preset 0 has been stored, this position will be called after initialization .
www . a vonic . e u
[SET PRESET]+[<number>]
[<number>]
[CLEAR PRESET]+[<number>]
: Camera Address No . 3
: Camera Address No . 4
