Summary of Contents for Avonic CM70-IP

  • Page 1 Avonic PTZ Camera 30/20x/12x zoom CM70-IP/CM71-IP/CM73-IP www.avonic.com | User Manual | Version 1.02...

  • Page 2: Disclaimer, Contact And Ce Marking

    “look and feel” and arrangement of such Content, contained in this Manual is owned, controlled or licensed by or to Avonic, and is protected by trade dress, copyright, patent and trademark laws, and various other intellectual property rights and unfair competition laws.

  • Page 3: Eu Declaration Of Conformity

    EU Declaration of Conformity The Avonic Declaration of Conformity is in accordance with EN ISO/IEC 17050-1 and generated using the ProductIP compliance platform. Table 1: EU Declaration of Conformity DOCIP 819694 Declaration number: Name and address of Avonic manufacturer / EU-AR:...

  • Page 4: Important Information

    Important Information Liability Avonic will NOT be held responsible for any damage or injury caused by unqualified persons carrying out these tasks, or by not following the instructions in this Manual. Intended Use and Non-Intended Use Installation The following applies to the installation of the camera: •...
  • Page 5 On-Screen Display Power over Ethernet Pan / Tilt / Zoom RTMP Real-Time Messaging Protocol RTSP Real-Time Streaming Protocol Shutter Auto Exposure Serial Digital Interface Stock Keeping Unit Signal to Noise Ratio Secure Reliable Transport User Datagram Protocol User Manual | www.avonic.com...

  • Page 6: Table Of Contents

    Serial Connecting via RS-232 or RS-485..............17 Connecting via LAN....................19 Operation..........................20 WebGUI........................20 Login........................20 LOCAL......................... 20 AUDIO......................... 21 VIDEO......................... 22 Using the Remote Control..................... 42 a. Power......................42 b. Set........................42 c. Camera Select....................43 d. Number Keys....................43 e. Focus + -......................43 User Manual | www.avonic.com...
  • Page 7 Appendix A - VISCA Settings and Command List..............58 VISCA over IP.......................58 Camera Return Commands................... 59 Camera Control Commands.................. 60 Inquiry Commands....................66 Appendix B - Dimensions....................... 70 Appendix C - HTTP API......................71 Appendix D - CMOS Image Sensor Characteristics..............90 User Manual | www.avonic.com...
  • Page 8 White Flecks......................... 90 Aliasing.........................90 Focal Plane........................90 Flash Band........................90 Flicker...........................90 User Manual viii | www.avonic.com...

  • Page 9: Introduction

    This Manual describes the safety precautions and the instructions for safe unpackaging, installation, operation, maintenance and disposal of the Avonic CM70-IP, CM71-IP and CM73-IP cameras. In this Manual, the Avonic CM70-IP, CM71-IP and CM73-IP cameras are referred to as the 'Product'. Target Audience This Manual is developed for installation technicians who install the Product at client sites, and for IT professionals who are responsible for operating the Product.

  • Page 10: Safety

    • Set up this Product on a hard, stable surface or mount it to a wall or ceiling. • ONLY use an Avonic mount for mounting to a wall or ceiling. • Ensure the mounting construction is capable of supporting four times the weight of the Product. (See 'General Specifications >...

  • Page 11: Ventilation

    • Don’t open this Product and don’t attempt to repair it yourself. Disassembling the Product may damage it or may cause injury to you. • If this Product is damaged, malfunctioning, or if it comes into contact with liquid, contact Avonic or an Avonic Authorized Service Provider.

  • Page 12: Product Overview

    IP outputs. Features Each camera in the Avonic CM70-IP / CM71-IP / CM73-IP series has the following features: • 20x/12x/30x Optical Zoom glass lens. • High SNR CMOS combined with Digital Noise Reduction (DNR) for a clear picture, even under very low light conditions.

  • Page 13: Unpacking

    2. Handling Precautions 3. Unpacking the Camera 4. Return Procedure Package Contents The following tables contains an overview of the package contents of the Product. Quantity Description Avonic SKU 1 pc PTZ Camera AV-CM70/71/73-IP-B/W 1 pc Remote Control AV-CM40-RC 1 pc...

  • Page 14: Unpacking The Camera

    The camera should be in its protective foam as follows: Figure 5: Camera in Foam 3. Verify that the plastic camera bag is sealed. If this is NOT the case, contact Avonic and stop here. 4. Break the seal of the sealed camera bag.

  • Page 15: Mounting And Installation

    Mounting on Wall or Ceiling The following accessories (AV-MT200 and AV-MT250) are separately available if the client wants to mount the camera to the wall or ceiling. Contact your Avonic reseller or local distributor for purchasing details. Table 2: Camera Accessories...

  • Page 16: Connecting The Components To The Camera

    OSD Menu of the camera using the controller. The camera(s) can be connected via a serial connection to USB, HDMI, SDI, RS-232, RS-485, or via a LAN Ethernet connection. Each of these options is described below. User Manual | www.avonic.com...

  • Page 17: Connecting Via Usb, Hdmi Or Sdi

    Connect the controller to the back of the camera via the RS-232 cables as shown in the figures below: Figure 7: RS-232 Interface (Mini DIN-8) Figure 8: RS-232 Cable and Interface Connection (Mini DIN-8 and Windows DB-9) User Manual | www.avonic.com...
  • Page 18 120Ω-impedance resistor. 2. Ensure that the maximum distance from the bus t of the camera or controller is 5m. If you use only ONE camera, the impedance resistor is not needed. Figure 11: RS-485 Network Connection Diagram User Manual | www.avonic.com...

  • Page 19: Connecting Via Lan

    Connecting via LAN Avonic IP cameras can be controlled by any device using the Visca over IP protocol (see the command list in Appendix A - VISCA Settings and Command List). Settings By default, the IP address of the camera is "192.168.5.163" with "admin" for both the username and password.

  • Page 20: Operation

    After a successful logon, the WebGUI is displayed. Here, you can select various tabs that are described below. LOCAL In this tab, you can see a preview of the camera IP video output. For example: Figure 14: WebGUI > Preview User Manual | www.avonic.com...

  • Page 21: Audio

    6. Select the Channel: Mono or Stereo. 7. Set the Input Volume: 1 ~ 10. 8. Set the Audio Delay (ms): 0 ~ 200. 9. Click SAVE to apply your settings. A small confirmation dialogue appears in the bottom right corner. User Manual | www.avonic.com...

  • Page 22: Video

    5-60 frames per second 5-30 frames per second I FrameInterval 1-300 1-150 I Framemin. QP 10-51 10-51 Streamname live/av0 live/av1 RTSP Link rtsp://<ip-address>/live/av0 rtsp://<ip-address>/live/av1 RTP Package Small Package (standard MTU size, 1500 bytes) Big Package (approx. 60kb MTU size) User Manual | www.avonic.com...
  • Page 23 1. (* in the table ) Enter a value for Password for stream encryption if the selected Protocol Type is "SRT". 2. Click SAVE to apply your settings. A small confirmation dialogue appears in the bottom right corner. User Manual | www.avonic.com...
  • Page 24 4000 (default) 4002 (default) Access Method rtp://224.1.2.3:4000 rtp://224.1.2.3:4002 Click SAVE to apply your settings. A small confirmation dialogue appears in the bottom right corner. VIDEO - Camera Settings Figure 19: WebGUI > VIDEO > Camera Settings User Manual | www.avonic.com...
  • Page 25 ‘Medium’, the camera will not react to sudden and short changes in the picture. Note that in some cases the autofocus will have some difficulties to focus. We strongly recommend to focus manually to avoid autofocus issues. See also the Troubleshooting/ Image in this manual. User Manual | www.avonic.com...
  • Page 26 DRC increases. Manual Exposure Mode Figure 23: WebGUI > VIDEO > Camera Settings > Manual Exposure Mode In Manual exposure mode, you can manually set the shutter, Iris and DRC options. User Manual | www.avonic.com...
  • Page 27 Gain limit and DRC are available to compensate for challenging light conditions. Bright Mode This mode is to try and create a decent image when the light conditions are exceptionally poor. Figure 24: WebGUI > VIDEO > Camera Settings > Bright Exposure Mode User Manual | www.avonic.com...
  • Page 28 How saturated the image’s colors are. 0% would produce a black and white image. Hue or tint The balance between green and red. 0 is green, 14 is red. AWB Sensitivity This setting indicates how quickly the camera responds to changing light settings. User Manual | www.avonic.com...
  • Page 29 The frame rate will drop to 10 frames per second, to catch as much light on the sensor as possible. If this mode is needed to produce a picture, add more light to the scene to get better results. User Manual | www.avonic.com...
  • Page 30 Here, you can choose the style you want, such as Default (standard setting), Normal (which makes the picture more ‘natural’), Clarity (makes the picture more clear), Bright (which makes the picture more bright) and Soft (which softens the picture). User Manual | www.avonic.com...
  • Page 31 If you have purchased the additional license for SRT and the Customizable Color Matrix (CCM), the Camera Settings menu will have an extra tab in the camera settings: CCM. The CCM is intended to finetune the color settings of the camera to seamlessly integrate with an existing camera system. User Manual | www.avonic.com...
  • Page 32 You can use Scale size automatically for both main stream and sub stream. If checked, the camera name and time overlay will always scale with the image, keeping the proportions intact. Click SAVE to apply your settings. A small confirmation dialogue appears in the bottom right corner. User Manual | www.avonic.com...
  • Page 33 Click SAVE (not shown here) to apply your settings. A small confirmation dialogue appears in the bottom right corner. Video output over IP cannot be a higher resolution than the physical SDI/HDMI output setting. User Manual | www.avonic.com...
  • Page 34 Caller Mode settings in the Streaming Video tab. See the respective figures below for the Listener and Caller Mode Settings, respectively. Figure 32: WebGUI > VIDEO > SRT (Listener Mode) Figure 33: WebGUI > VIDEO > Streaming Video (Caller Mode) User Manual | www.avonic.com...
  • Page 35 Figure 35: WebGUI > NETWORK > Ethernet Execute the following steps to save your settings: 1. Click SAVE to apply your settings. A small confirmation dialogue appears in the bottom right corner. 2. Reboot the camera. User Manual | www.avonic.com...
  • Page 36 If you have purchased the license for the premium features of this camera, you can enter the License key here to unlock these features. Reboot is not required as the license is instantly activated. You can acquire a license through your local sales channel or directly at Avonic. Execute the following steps to enter your license key: 1.
  • Page 37 You can manually set the time and date, or synchronize the time and date via a computer or an external server on the LAN or WAN. Either click SAVE to apply your manual settings, or SYNC to synchronize the time and date. User Manual | www.avonic.com...
  • Page 38 3. Follow the steps in the wizard. 4. Wait until the process finishes and reboots. 5. Refresh your browser and log in again after the reboot. Default If necessary, you can perform a factory reset. This restores all default settings. User Manual | www.avonic.com...
  • Page 39 'Auto' to let the camera detect which protocol is being used. Note that addressing is still needed, even with the automatic setting. Click SAVE to apply your settings. A small confirmation dialogue appears in the bottom right corner. User Manual | www.avonic.com...
  • Page 40 It is possible to increase the maximum pan and tilt speed, this can be useful in a conference system where quick action is necessary. The camera will produce slightly more noise when this setting is set to ‘high’. User Manual | www.avonic.com...
  • Page 41 (remote) controller. The higher the number, the faster it will switch. MJPEG Snapshot The Avonic CM7x-IP cameras are equipped with a MJPEG snapshot feature to, for example, implement into third party software. To access the MJPEG snapshot feature, use the following format: http://IP/img/capjpg/snapshot.jpg.

  • Page 42: Using The Remote Control

    2. Press the Power button again to turn the camera off. It will turn to the back when turned off, this is called the “privacy mode”. b. Set This button has no function with this camera. User Manual | www.avonic.com...

  • Page 43: Camera Select

    Set the camera to 'auto focus' or 'manual focus'. If the camera is configured to 'auto focus', the buttons [Focus + -] are disabled. If the camera is in 'manual focus' and the Zoom buttons are used, the camera automatically switches to 'auto focus'. User Manual | www.avonic.com...

  • Page 44: Zoom

    2. If the menu is not in English, press [*]+[#]+[4] to change the Menu language into English. m. Function Keys (F1/F2/F3/F4) 'c. Camera Select' Used to configure the IR channel of the camera. See above for instructions. n. Blank Buttons These buttons have NO function with this camera. User Manual | www.avonic.com...

  • Page 45: Other Key Combinations

    The camera returns to the video output setting of the rotary dial after a reboot. Use ONLY presets between 0-9 when using the Remote Control. For presets 10 or higher you need a serial or IP connection! User Manual | www.avonic.com...

  • Page 46: Osd Menu

    The OSD Menu is visible on the HDMI, SDI, USB and IP outputs. The OSD menu can be accessed by the Remote Control or an Avonic PTZ controller. Figure 49: OSD menu structure User Manual | www.avonic.com...

  • Page 47: Menu

    2. Use the arrow buttons to move the cursor to theitem to be set. Press the HOME button to enter the corresponding sub-menu. 3. Press [ ] to change settings. Press [MENU] again to go back. 2. SETUP Figure 51: OSD - SETUP User Manual | www.avonic.com...

  • Page 48: Camera

    3. CAMERA Figure 52: OSD - CAMERA 3.1 EXPOSURE Figure 53: OSD - EXPOSURE User Manual | www.avonic.com...

  • Page 49: Color

    3.2 COLOR Figure 54: OSD - COLOR 3.3 IMAGE The Flip function can be set, although the camera has an automatically flip function. Figure 55: OSD - IMAGE User Manual | www.avonic.com...

  • Page 50: Focus

    3.4 FOCUS Figure 56: OSD - FOCUS 3.5 NOISE REDUCTION Figure 57: OSD - NOISE REDUCTION 3.6 STYLE Figure 58: OSD - STYLE User Manual | www.avonic.com...

  • Page 51: Ptz

    4. PTZ Figure 59: OSD - PTZ 6. NETWORK SETTINGS Figure 60: OSD - NETWORK SETTINGS 7. VERSION Figure 61: OSD - VERSION 8. RESTORE DEFAULT Figure 62: OSD - RESTORE DEFAULT User Manual | www.avonic.com...

  • Page 52: Using The Select Switch

    • There are four ways to select the video output of the camera (OSD / direct button combination on the remote control / WebGUI / rotary dial). The rotary dial takes priority after a reboot, except on setting F, where all the outputs are defined digitally. User Manual | www.avonic.com...

  • Page 53: Maintenance

    • Do not film extreme bright objects for a prolonged period of time, such as sunlight, light sources, etc. • Do not operate in unstable lighting conditions, otherwise the produced image could be less than optimal. • Do not operate close to powerful electromagnetic radiation, such as TV or radio transmitters, etc. User Manual | www.avonic.com...

  • Page 54: Transport And Storage

    Specific guidelines apply to the environmental temperature and humidity when operating and storing the camera. See 'Operating humidity' and 'Storage temperature' in the provided Datasheet for the applicable values. User Manual | www.avonic.com...

  • Page 55: Disposal And Recycling

    In general, the term 'E-Waste' applies to items of all types of electrical and electronic equipment and its parts that have been discarded by the owner as waste without the intention of re-use. Avonic outsources the disposal and recycling of its E-Waste camera materials to the Stichting Open. https://stichting-open.org/ for more information about the disposal and recycling.

  • Page 56: Troubleshooting

    OSD. Noise Reduction Color issues Check the OSD settings for exposure, white balance, color temp, Red and Bluetuning. When experiencing image problems, you may also check Appendix D - CMOS Image Sensor Characteristics User Manual | www.avonic.com...

  • Page 57: Autofocus Issues

    4. Reset the factory default IP settings by pressing [*] [#] [Manual] and Reboot. Firmware update failed 1. Check firmware file integrity, download it again. 2. Make sure you are trying to flash the UVC file for the correct color camera (ARM is generic, UVC is color-dependent). User Manual | www.avonic.com...

  • Page 58: Appendix A - Visca Settings And Command List

    When using VISCA over IP, the ‘x’ in all the ‘8x’ addresses is always ‘1’, as the unique identifier is the IP address. VISCA over IP The Avonic IP camera is implemented with a TCP server. The TCP port number is 1259 by default and can be altered in the WebGUI.

  • Page 59: Camera Return Commands

    Command Not Executable 90 6y 41 FF Returned when a command cannot be (y: Execution com- executed due to current mand Socket No. Inquiry conditions. For example, command: 0) when commands controlling the focus manually are received during auto-focus. User Manual | www.avonic.com...

  • Page 60: Camera Control Commands

    Outdoor mode OnePush mode 8x 01 04 35 03 FF One Push WB mode Manual 8x 01 04 35 05 FF Manual Control mode OnePush trigger 8x 01 04 10 05 FF One Push WB Trigger User Manual | www.avonic.com...
  • Page 61 8x 01 04 0E 00 FF Exposure Compensation Amount Setting 8x 01 04 0E 02 FF Down 8x 01 04 0E 03 FF Direct pq: ExpComp Position 8x 01 04 4E 00 00 0p 0q FF User Manual | www.avonic.com...
  • Page 62 Freeze ON when running preset Preset Freeze OFF 8x 04 04 62 23 FF Freeze OFF when running preset SYS_Menu 8x 01 06 06 03 FF Turns the OSD menu On/ 8x 01 06 06 02 FF User Manual | www.avonic.com...
  • Page 63 0F 06 07 00 ~ 50 00 09 09 +170° (YYYY) Tilt range: -30° ~ +90° 0F 0E 04 05 ~ 00 05 01 00 (ZZZZ) Home 8x 01 06 04 FF Reset 8x 01 06 05 FF User Manual | www.avonic.com...
  • Page 64 8x 01 7E 010A 00 02 03 FF Tally Light RedON only with license Green 8x 01 7E 010A 00 03 02 FF Tally Light GreenON active) 8x 01 7E 010A 00 03 03 FF Tally Light OFF User Manual | www.avonic.com...
  • Page 65 8x 01 06 35 00 pp FF pp: Video Format 00: 1080p60 01:1080p50 02: 1080i60 03: 1080i50 04: 720p60 05: 720p50 06: 1080p30 07: 1080p25 08: 720p30 09: 720p25 0A: 1080p59.94 0B: 1080i59.94 0C: 720p59.94 0D: 1080p29.97 0E: 72029.97 User Manual | www.avonic.com...

  • Page 66: Inquiry Commands

    8x 09 04 55 FF 90 50 0p FF p: Flicker Settings(0: OFF, 1: 50Hz, 2: 60Hz) CAM_Aperture-ModeInq 8x 09 04 05 FF 90 50 02 FF Auto Sharpness (Sharpness) 90 50 03 FF Manual Sharpness User Manual | www.avonic.com...
  • Page 67 Pan-tiltPosInq 8x 09 06 12 FF 90 50 0w 0w 0w 0w wwww: Pan Position 0z 0z 0z 0z FF zzzz: Tilt Position CAM_GainLimitInq 8x 09 04 2C FF 90 50 0q FF p: Gain Limit User Manual | www.avonic.com...
  • Page 68 90 50 05 FF Manual CAM_RGainInq 8x 09 04 43 FF 90 50 00 00 0p 0q FF pq: R Gain CAM_BGainInq 8x 09 04 44 FF 90 50 00 00 0p 0q FF pq: B Gain User Manual | www.avonic.com...
  • Page 69 Iris Position CAM_BrightPosInq 8x 09 04 4D FF 90 50 00 00 0p 0q FF pq: Bright Position CAM_PowerInq 8x 09 04 00 FF y0 50 02 FF y0 50 03 FF Off Off (Standby) User Manual | www.avonic.com...

  • Page 70: Appendix B - Dimensions

    Appendix B - Dimensions User Manual | www.avonic.com...

  • Page 71: Appendix C - Http Api

    User Manual | www.avonic.com...
  • Page 72 Command Setting szCmd {“SetEnv”:{“ArmPtz”:{“nPresetPanSpeed”:0}}} nPresetPanSpeed 0 - 24 Set Preset Tilt Speed Command Code Command Setting szCmd {“SetEnv”:{“ArmPtz”:{“nPresetTiltSpeed”:0}}} nPresetTiltSpeed 0 - 20 Set Preset Zoom Speed Command Code Command Setting szCmd {“SetEnv”:{“ArmPtz”:{“nPresetZoomSpeed”:0}}} nPresetZoomSpeed 0 - 7 User Manual | www.avonic.com...
  • Page 73 Focus add start focusadd_start Focus add stop focusadd_stop Focus decrease start focusdec_start Focus decrease stop focusdec_stop Preset Code {“SysCtrl”:{“PtzCtrl”:{“nChanel”:0,”szPtzCmd”:”preset_set”,”byValue”:0}}} Command Setting Function Command nChanel ByValue 0, 254 szPtzCmd Set preset preset_set Call preset preset_call Clean preset preset_clean User Manual | www.avonic.com...
  • Page 74 44100 can only be 8000.) 48000 Sample Bits {“SetEnv”:{“Audio”: nSampleBits {“nSampleBits”:16}}} Bit Rate {“SetEnv”:{“Audio”:{“nBitRate”:96}}} nBitRate Channel {“SetEnv”:{“Audio”:{“nChannel”:2}}} nChannel 1: Mono Stereo Input {“SetEnv”:{“Audio”:{“nInpVolume”:5}}} nInpVolume (range from Exp:[1, 10] Volume 1 to 10.) User Manual | www.avonic.com...
  • Page 75 Compared to webpage and this, you can size) know the different value meaning different image size. Image Size {“SetEnv”:{“VideoEncode”: [{“stMaster”: emImageSize 5: 1920*1080 {“emImageSize”:4},”nChannel”:0}]}} 4: 1280*720 9: 640*480 27: 320*180 26: 640*360 Rate Control {“SetEnv”:{“VideoEncode”: [{“stMaster”: emBitRateCtrl 0: CBR {“emBitRateCtrl”:1},”nChannel”:0}]}} 1: VBR User Manual | www.avonic.com...
  • Page 76 NOTE: When modifying one param, you shoud take along wHostPort. Otherwise, the host port will be zero. Function Code Command Setting Enable {“SetEnv”:{“StreamPublish”: bEnable 0: off [{“stMaster”:{“wHostPort”:1935, 1: on “bEnable”:1,“nProtolType”:3},”nChannel”:0}]}} Protol Type nProtolType 2: srt 3: rtmp Host Address {“SetEnv”:{“StreamPublish”:[{“stMaster”: szHostUrl user-defined {“wHostPort”:1935, “nProtolType”:3”,szHostUrl”: ”192.168.5.12”},”nChannel”:0}]}} User Manual | www.avonic.com...
  • Page 77 0: off {“bEnable”:1, ”wMultiCastPort”:4004}, 1: on ”nChannel”:0}]}} Protol Type {“SetEnv”:{“StreamRTPMulticast”: nProtolType 0: RTP [{“stMaster”:{“bEnable”:1, ”nProtolType”:1, 1: TS ”wMultiCastPort”:4004},”nChannel”:0}]}} Multicast Address {“SetEnv”:{“StreamRTPMulticast”: SzMultiCastUrl 224.0.0.0~ [{“stMaster”:{“bEnable”:0, 255.255.255.0 ”szMultiCastUrl”:”224.1.2.23”,”wMultiCastPort”:4004}, ”nChannel”:0}]}} Multicast Port {“SetEnv”:{“StreamRTPMulticast”:[{“stMaster”: wMultiCastPort Even [0, 65535] {“bEnable”:1, ”wMultiCastPort”:4004}, ”nChannel”:0}]}} User Manual | www.avonic.com...
  • Page 78 Exposure: Auto {“SetEnv”:{“VideoParam”: [{“stExp”: expcomp_mode 2: {“expcomp_mode”:2},”nChannel”:0}]}} {“SetEnv”:{“VideoParam”: [{“stExp”: Expcomp [0, 14] Level {“expcomp”:8},”nChannel”:0}]}} {“SetEnv”:{“VideoParam”: [{“stExp”: backlight {“backlight”:2},”nChannel”:0}]}} Video Configure Video Parameters Exposure: Auto Function Code Command Setting Flicker {“SetEnv”: antiflicker {“VideoParam”: [{“stExp”: 50HZ {“antiflicker”:0},”nChannel”:0}]}} 60HZ User Manual | www.avonic.com...
  • Page 79 [0, 15] {“VideoParam”: [{“stExp”: {“gainLimit”:5},”nChannel”:0}]}} Iris {“SetEnv”:{“VideoParam”: nIris [0, 12] [{“stExp”:{“stIris”: {“nIris”:12}},”nChannel”:0}]}} {“SetEnv”: [0, 8] {“VideoParam”: [{“stExp”: {“drc”:6},”nChannel”:0}]}} Exposure: Bright Bright {“SetEnv”: bright [0, 23] {“VideoParam”: [{“stExp”: {“bright”:0},”nChannel”:0}]}} Flicker, G.Limit, You can find the same configure at User Manual | www.avonic.com...
  • Page 80 Saturation {“SetEnv”:{“VideoParam”: saturation [0, 14] [{“stColor”: {“saturation”:0},”nChannel”:0}]}} {“SetEnv”:{“VideoParam”: [0, 14] [{“stColor”: {“hue”:14},”nChannel”:0}]}} {“SetEnv”:{“VideoParam”: awbsens Sensitivity [{“stColor”: Middle {“awbsens”:0},”nChannel”:0}]}} High Image Bright {“SetEnv”: luminance [0, 4] {“VideoParam”: [{“stImg”: {“luminance”:0},”nChannel”:0}]}} Contrast {“SetEnv”: contrast [0, 14] {“VideoParam”: [{“stImg”: {“contrast”:0},”nChannel”:0}]}} User Manual | www.avonic.com...
  • Page 81 {“SetEnv”: {“VideoParam”: [{“stImg”: {“nAutoFlipV”:2},”nChannel”:0}]}} DZoom {“SetEnv”: nEZoom {“VideoParam”: [{“stImg”: {“nEZoom”:3},”nChannel”:0}]}} NR-2D {“SetEnv”: noise2D [0, 8] {“VideoParam”: [{“stNR”: {“noise2D”:0},”nChannel”:0}]}} NR-3D {“SetEnv”: noise3D [0, 8] {“VideoParam”: [{“stNR”: Auto {“noise3D”:0},”nChannel”:0}]}} dhotpixel Dynamic Hot {“SetEnv”:{“VideoParam”: [0, 5] [{“stNR”: Pixel {“dhotpixel”:3},”nChannel”:0}]}} User Manual | www.avonic.com...
  • Page 82 0: Not Show {“bEnable”:1}, ”nChannel”:0}]}} 1: Show Video Configure Video OSD Set video parameters Function Code Command Setting Time FontColor {“SetEnv”:{“VideoOsd”:[{“stTime”:{“stFtColor”: byAlpha {“byAlpha”:128,”byRed”:255,”byGreen”:255, white rgb (255,255,255) ”byBlue”:0}},”nChannel”:0}]}} black rgb (0,0,0) yellow rgb (255,255,0) rgb (255,0,0) blue rgb (0,0,255) User Manual | www.avonic.com...
  • Page 83 Time: {“SetEnv”:{“VideoOsd”: [{“stTime“: nYPos [0, 10000] {“nYPos”:1200},”nChannel”:0}]}} Title: {“SetEnv”:{“VideoOsd”: [{“stTitle”: {“nYPos”:1200},”nChannel”:0}]}} OSD Font Size Get OSD font size parameters Code {“GetEnv”:{“TTFFontSize”:{“nChannel”:-1}}} Set video parameters Code {“SetEnv”:{“TTFFontSize”:{“nFontSize”:[48,48],”bAutoSize”:1}}} Function Code Command Setting bAutoSize 0: off,1: on nFontSize [8,200] User Manual | www.avonic.com...
  • Page 84 720P59.94 720P29.97 Get network SRT parameters Code {“GetEnv”:{“NetWork”:{“nChannel”:-1}}} Set network SRT parameters Code {“SetEnv”:{“NetWork”:{“stSrt”: {“wSrtLen”:0,”wSrtPort”:9000,”szSrtPin”:”xxxxxxxxxx”}}}} Function Code Command Setting wSrtLen [0-32] crypto key length in bytes Port SRT wSrtPort Default 9000 Password stream szSrtPin user-defined encryption User Manual | www.avonic.com...
  • Page 85 [0, 65535] Ethernet Get Ethernet parameters Code {“GetEnv”:{“NetWork”:{“nChannel”:-1}}} Set Ethernet parameters Code “SetEnv”:{“NetWork”:{“stEth”:[{“byValid”:5,”szIPAddr”:”192.168.5.126”,”szSubMask”: ”255.255.255.0”,”szMacAddr”:”E4:77:D4:01:8A:49”,”szGateway”:”192.168.5.1”, ”bDefault”:1}]}}} Function Code Command Setting DHCP {“SetEnv”:{“NetWork”:{“stEth”:[{“byValid”:5}]}}} byValid 5:off 7: on IP Address {“SetEnv”:{“NetWork”:{“stEth”:[{“szIPAddr”:”192.168.5.127”}]}}} Subnet Mask {“SetEnv”:{“NetWork”:{“stEth”: [{“szSubMask”:”255.255.255.0”}]}}} Default {“SetEnv”:{“NetWork”:{“stEth”:[{“szGateway”:”192.168.5.1”}]}}} Gateway User Manual | www.avonic.com...
  • Page 86 Function Code Command Setting Device Name szDevName user-defined, cannot use white space Device ID szDeviceID cannot modify Language nLanguage 0: Simplified Chinese 2: English License Get License parameters Code :{“QueryState”:{“QueryLicenseState”:{}}} Set License parameters Code {“SetEnv”:{“LicenseKey”: {“bLicenseEnable”:0,”szKeyText”:”483B4EB1D0”}}} User Manual | www.avonic.com...
  • Page 87 0: GMT 1: GMT+01:00 2: GMT+02:00 3: GMT+03:00 4: GMT+03:30 5: GMT+04:00 6: GMT+04:30 7: GMT+05:00 …… 13: GMT+08:00 …… 20: GMT-01:00 …… 31: GMT-11:00 32: GMT-12:00 Hour Type {“SetEnv”:{“SysTime”:{“nHourType”:0}}} nHourType 0: 24 Hours 1: 12 Hours User Manual | www.avonic.com...
  • Page 88 Authority nUserType 0: admin 1: user1 or user 2 User Name szUserName user-define: do not use white space Password szPassword user-define,do not use white space Note: This command must set three users at the same time. User Manual | www.avonic.com...
  • Page 89 {“SysCtrl”:{“Default”:{}}} Reboot Code {“SysCtrl”:{“Reboot”:{}}} The URL supports to set all params at one time and also can set one of them through split URL into one other command. Different commands can be found at different settings. User Manual | www.avonic.com...

  • Page 90: Appendix D - Cmos Image Sensor Characteristics

    See the Focal Plane explanation above for a clarification ofthis occurrence. Flicker If you are recording under lighting that is produced by discharge tubes (such as fluorescent, sodium or mercury-vapor lamps), the screen may flicker, colors may vary, or horizontal stripes may appear distorted. User Manual | www.avonic.com...
  • Page 91 Depending on lighting types, such occurrences may not be improved with the anti-flicker setting. It is recommended to set the shutter speed to 1/100s in areas of 50 Hz power supply frequency, and to 1/60s in areas of 60 Hz power supply frequency. User Manual | www.avonic.com...
  • Page 92 Avonic PTZ Camera 30/20x/12x zoom CM70-IP/CM71-IP/CM73-IP Version 1.02 © October 2021...
