  • Page 7: Table Of Contents

    Table of Contents 1. Overview ..........................7 Purpose ..............................7 Features ..............................7 2. Power Supply ........................8 Requirements ............................. 8 Power-Up Behaviour ..........................8 3. Board Layout ........................9 Component Layout ............................. 9 Board Dimensions ............................ 10 Component Placement ..........................11 4.
  • Page 8: Overview

    May 02, 2013 1. Overview Purpose This RSK is an evaluation tool for Renesas microcontrollers. This manual describes the technical details of the RSK hardware. The Quick Start Guide and Tutorial Manual provide details of the software installation and debugging environment.
  • Page 9: Power Supply

    When the RSK is purchased, the RSK board has the ‘Release’ or stand-alone code from the example tutorial software pre-programmed into the Renesas microcontroller. On powering up the board the user LEDs will start to flash. After 200 flashes or after pressing any switch, the LEDs will flash at a rate controlled by the potentiometer.
  • Page 10: Board Layout

    RSKRX210B 3. Board Layout 3. Board Layout Component Layout Figure 3-1 below shows the top component layout of the board. Micon Pin Headers Reset Switch Application Headers RS232 Serial Port Debug LCD Header Power Jack Power LED E1 Interface RX210 (B Mask) User LEDs Micon Pin Headers...
  • Page 11: Board Dimensions

    RSKRX210B 3. Board Layout Board Dimensions Figure 3-2 below gives the board dimensions and connector positions. All the through-hole connectors are on a common 0.1 inch grid for easy interfacing. 115.00 106.68 86.36 55.88 50.80 45.00 SERIAL RX210 (B Mask) 27.00 35.56 48.26...
  • Page 12: Component Placement

    RSKRX210B 3. Board Layout Component Placement Figure 3-3 below shows placement of individual components on the top-side PCB. Component types and values can be looked up using the board schematics. Figure 3-3: Top-Side Component Placement R20UT2604EG0100 Rev. 1.00 Page 11 of 42 May 02, 2013...
  • Page 13: Connectivity

    RSKRX210B 4. Connectivity 4. Connectivity Internal RSK Connections The diagram below shows the RSK board components and their connectivity to the MCU. Low Voltage Supply MCU Current Draw Power Jack Mode Test Point Application Board Headers 16KBit I C EEPROM Micon Pin Headers RX210 (B Mask) Debug LCD...
  • Page 14: Debugger Connections

    RSKRX210B 4. Connectivity Debugger Connections The diagram below shows the connections between the RSK, E1 debugger and the host PC. User Interface Cable USB Cable E1 Emulator Host PC Figure 4-2: Debugger Connection Diagram R20UT2604EG0100 Rev. 1.00 Page 13 of 42 May 02, 2013...
  • Page 15: User Circuitry

    RSKRX210B 5. User Circuitry 5. User Circuitry Reset Circuit A reset control circuit is not fitted to the RSK, as the MCU is capable of voltage and power-on detection. Resets are handled internally, and reset switch is connected directly to nRES on the MCU (pin 10). Clock Circuit A clock circuit is fitted to the RSK to generate the required clock signal to drive the MCU, and associated peripherals.
  • Page 16: Leds

    RSKRX210B 5. User Circuitry LEDs There are five LEDs on the RSK board. The function of each LED, its colour, and its connections are shown in Table 5-3. Colour Function MCU Connection POWER Green Indicates the power status No connection LED0 Green User operated LED.
  • Page 17: Rs232 Serial Port

    RSKRX210B 5. User Circuitry RS232 Serial Port Connections between the RS232 header and the microcontroller are listed in Table 5-5 below. SCI Signal Function MCU Connection RS232 Connection TXD0 SCI0 Transmit Signal. P20, pin 28 Pin 2 RXD0 SCI0 Receive Signal. P21, pin 27 Pin 3 TXD1...
  • Page 18: Configuration

    RSKRX210B 6. Configuration 6. Configuration Modifying the RSK This section lists the option links that are used to modify the way RSK operates in order to access different configurations. Configurations are made by modifying link resistors or headers with movable jumpers or by configuration DIP switches A link resistor is a 0Ω...
  • Page 19: Adc Configuration

    RSKRX210B 6. Configuration ADC Configuration Table 6-2 below details the function of the option links associated with the Analog-to-Digital circuit. Reference Link Fitted Configuration Link Removed Configuration Related Ref. Connects the MCU (AVSS0, pin 99) to Disconnects (AVSS0, CON_AVSS. pin 99) from CON_AVSS. Connects the potentiometer (RV1, Disconnects the potentiometer (RV1, pin 3) to Board_VCC.
  • Page 20: E1 Debugger Interface

    RSKRX210B 6. Configuration E1 Debugger Interface Table 6-3 below details the function of the option links associated with serial port configuration. Reference Link Fitted Configuration Link Removed Configuration Related Ref. R279 Connects SCK1 (MCU, pin 21) to the Disconnects SCK1 (MCU, pin 21) R363, R380 E1 connector (pin 1).
  • Page 21: Rs232 Serial Port Configuration

    RSKRX210B 6. Configuration RS232 Serial Port Configuration Table 6-4 below details the function of the option links associated with serial port configuration. Reference Link Fitted Configuration Link Removed Configuration Related Ref. Connects the RS232 IC (U9, pin 9) to Disconnects the RS232 IC (U9, R55, J7 the serial port (pin 7).
  • Page 22 RSKRX210B 6. Configuration External Bus Configuration Table 6-5 below details the function of option links related to configuring the MCU’s external bus. Reference Link Fitted Configuration Link Removed Configuration Related Ref. R309 Connects A19_MTIOC4D (MCU, pin 49) Disconnects A19_MTIOC4D (MCU, to the application header (JA2, pin 18).
  • Page 23 RSKRX210B 6. Configuration Reference Link Fitted Configuration Link Removed Configuration Related Ref. R327 Connects D9_IO1 (MCU, pin 77) to the Disconnects D9_IO1 (MCU, pin 77) application header (JA1, pin 16). from the application header (JA1, pin 16). R328 Connects D8_IO0 (MCU, pin 78) to the Disconnects D8_IO0 (MCU, pin 78) application header (JA1, pin 15).
  • Page 24: Irq & General I/O Pin Configuration

    RSKRX210B 6. Configuration IRQ & General I/O Pin Configuration Table 6-6 below details the function of the option links associated with IRQ and general I/O pin configuration. Reference Link Fitted Configuration Link Removed Configuration Related Ref. R303 Connects LED1_MTCLKB (MCU, pin Disconnects LED1_MTCLKB (MCU, R334 31) to the application header (JA2,...
  • Page 25 RSKRX210B 6. Configuration Reference Link Fitted Configuration Link Removed Configuration Related Ref. R351 Connects NMIn (MCU, pin 15) to Disconnects NMIn (MCU, pin 15) GROUND. from GROUND. R361 Connects RXD1 (MCU, pin 20) to the Disconnects RXD1 (MCU, pin 20) application header (JA6, pin 7).
  • Page 26: User Switch Configuration

    RSKRX210B 6. Configuration User Switch Configuration Table 6-7 below details the function of the option links associated with user switches. Reference Link Fitted Configuration Link Removed Configuration Related Ref. Connects the MCU (nRES, pin 10) Disconnects the MCU (nRES, pin 10) directly to the RES switch.
  • Page 27: Power Supply Configuration

    RSKRX210B 6. Configuration Power Supply Configuration Table 6-8 below details the function of the option links associated with power supply configuration. Reference Link Fitted Configuration Link Removed Configuration Related Ref. Bypasses current measurement Allows the current consumption of the jumper J14. MCU to be measured across J14.
  • Page 28: Clock Configuration

    RSKRX210B 6. Configuration 6.10 Clock Configuration Table 6-10 below details the function of the option links associated with clock configuration. Reference Link Fitted Configuration Link Removed Configuration Related Ref. Connects CON_XCOUT (J1, pin 9) to Disconnects CON_XCOUT (J1, R47, R293 the MCU (XCOUT, pin 9).
  • Page 29: Iic Eeprom Configuration

    RSKRX210B 6. Configuration 6.12 IIC EEPROM Configuration Table 6-12 below details the function of the option links associated with debug LCD configuration. Reference Link Fitted Configuration Link Removed Configuration Related Ref. R285 Connects the EEPROM IC (U10, pin 7) Disconnects the EEPROM IC (U10, to Board_VCC (enable write-protection) pin 7) from Board_VCC.
  • Page 30: Headers

    7. Headers 7. Headers Application Headers This RSK is fitted with application headers, which can be used to connect compatible Renesas application devices or as easy access to MCU pins. Table 7-1 below lists the connections of the application header, JA1.
  • Page 31 RSKRX210B 7. Headers Table 7-3 below lists the connections of the BUS application header, JA3 Bus Application Header JA3 Circuit Net Name MCU Pin Circuit Net Name MCU Pin CSan CSbn CScn HWRn LWRn Table 7-3: Bus Application Header JA3 Connections R20UT2604EG0100 Rev.
  • Page 32 RSKRX210B 7. Headers Table 7-4 below lists the connections of the application header, JA5. Application Header JA5 Circuit Net Name MCU Pin Circuit Net Name MCU Pin CAN1TX CAN1RX CAN2TX CAN2RX IRQ4 IRQ5 M2_UD M2_Uin M2_Vin M2_Win M2_Toggle M2_POE M2_TRCCLK M2_TRDCLK M2_Up M2_Un...
  • Page 33 RSKRX210B 7. Headers Microcontroller Pin Headers This RSK is fitted with MCU pin headers, which are used to access all the MCU’s pins. Table 7-6 below lists the connections of the pin header, J1. Pin Header J1 Circuit Net Name MCU Pin Circuit Net Name MCU Pin...
  • Page 34 RSKRX210B 7. Headers Table 7-7 below lists the connections of the pin header, J2. Pin Header J2 Circuit Net Name MCU Pin Circuit Net Name MCU Pin SCK0 RXD0_MTIOC1B TXD0 LED3_MTIOC3B LED2_MTIOC3D LED1_MTCLKB LED0_MTCLKA SDA_TMO3 DLCD7 DLCD6 DLCD5_TMO0 DLCD4 nWAIT BCLK_P53 nWR1 A19_MTIOC4D...
  • Page 35 RSKRX210B 7. Headers Table 7-8 below lists the connections of the pin header, J3. Pin Header J3 Circuit Net Name MCU Pin Circuit Net Name MCU Pin A15_TXD9 A14_RXD9 A13_SCK9 A11_MTIOC0A A9_MTIOC0C UC_VCC A8_MTIC5W GROUND A6_MTIC5V A4_MTIC5U A1_MTIOC0B D15_IO7 D14_IO6 D13_IO5 D12_IO4 D11_IO3...
  • Page 36 RSKRX210B 7. Headers Table 7-9 below lists the connections of the pin header, J4. Pin Header J4 Circuit Net Name MCU Pin Circuit Net Name MCU Pin D10_IO2 D9_IO1 D8_IO0 D7_POE0 D5_IRQ5 D4_IRQ4 D3_IRQ3 D2_IRQ2 D1_IRQ1 D0_IRQ0 AN007 AN006 AN005 AN004 AN003 AN002...
  • Page 37: Code Development

    8. Code Development Overview For all code debugging using Renesas software tools, the RSK board must be connected to a PC via an E1/E20 debugger. An E1 debugger is supplied with this RSK product. For further information regarding the debugging capabilities of the E1/E20 debuggers, refer to E1/E20 Emulator Additional Document for User's Manual (R20UT0399EJ).
  • Page 38: Address Space

    RSKRX210B 8. Code Development Address Space Figure 8-1 below details the address space of the MCU. The MCU fitted to the RSK has 1MB of ROM. For further details, refer to the RX210 Group Hardware Manual. Figure 8-1: MCU Address Space Diagram R20UT2604EG0100 Rev.
  • Page 39: Additional Information

    Copyright This document may be, wholly or partially, subject to change without notice. All rights reserved. Duplication of this document, either in whole or part is prohibited without the written permission of Renesas Electronics Europe Limited. © 2013 Renesas Electronics Europe Limited. All rights reserved.
  • Page 40 REVISION HISTORY RSK RX210B User’s Manual Rev. Date Description Page Summary  1.00 May 02, 2013 First Edition issued...
  • Page 41 Renesas Starter Kit User’s Manual: User’s Manual Publication Date: Rev. 1.00 May 02, 2013 Published by: Renesas Electronics Corporation...
  • Page 42 SALES OFFICES Refer to "http://www.renesas.com/" for the latest and detailed information. Renesas Electronics America Inc. 2880 Scott Boulevard Santa Clara, CA 95050-2554, U.S.A. Tel: +1-408-588-6000, Fax: +1-408-588-6130 Renesas Electronics Canada Limited 1101 Nicholson Road, Newmarket, Ontario L3Y 9C3, Canada...
  • Page 43 RX210 Group (B Mask) R20UT2604EG0100...
