ITech IT8211 User Manual page 7

Input on/off
Press key at the front panel
On/Off
to toggle the input on/off. Disable t
the input (zero current) does not
affect the programmed setting. The
input will return to the previously
programmed values when the input
is enabled again.
view function
The electronic load usually display
the actual voltage and current value,
and then press
will change
V to SV
the preset voltage, current or
resistance value and the actual power,
and press
C View
to show an actual value.
OCP function
Press key, and then press
Shift Shift
(Setup) key, OCP LED will be lit.
Use key and knob
B B
A A
set OCP value.
NOTE
The input of electronic load will be
turned off automatically if the OCP value
is less than the actual current value.
Default OCP setting is 30A,
Real-time reveal (REL)
After setting OCP, press
the REL setting, use the knob
select ON/OFF. ON means the REL
function is turn on; OFF means the REL
function is turn off. Press
confirm.
Key sound (BEEP)
After setting REL, Press
the BEEP setting. Use the knob
to turn the knob sound ON or OFF.
key ,the light
C View
, the load display
key, it will be back
C View
to
View
C
to enter
to
to
C View
to enter
C C
