6) Press key to enter Low Voltage
C View
setting. use cursor keys
knob to set the low limit of the input voltage.
Right figure set the Low Voltage as 0.00V.
7) Press key to enter High Current
C View
setting, use cursor keys
knob to set the high limit of the input
current. Right figure set the High Current as
30.00A.
8) Press key to enter Low Current
C View
setting, use cursor keys
knob to set the low limit of the input
current. Right figure set the Low Current as
0.00A.
9) Repeat step 1 settings, in turn set 5 steps:
1/2/2V/5S/60V/0V/30A/0A；
2/3/10Ω/5S/60V/0V/30A/0A；
3/1/2A/5S/60V/0V/30A/0A；
4/1/0A/5S/60V/0V/30A/0A (because the total
steps is less than 25 steps, so the last step
should be CC/0A.)
10) Press
View
C
press and
View
C
menu, the instrument will save the setting
automatically.
Press key to run the list file.
A A
NOTE: if the total steps is more than 25, e.g.
30 steps. press
A A
steps, press
B B
and the
A A B B
and the
A A B B
A A B B
key to finish the setting, and
keys to exit the edit
Shift Shift
key to run the previous 25
key to run the last 5 steps.
