ITech IT8211 User Manual page 13

11) When past the test successfully, the
instrument display as normal; when fail to
pass the test, the instrument will display
as right figure, display wrong step, alarm
3 second and shut the input. Right figure
show the condition the first step not pass.
Step value for Cursor Position
Cursor position
A
B
C
D
Voltage
Stepping values
10V
1V
0.1V
0.01V
IT8211 60V/30A/150W
ITECH
DC Electronic Load
A
B
Current
Stepping values
Stepping
Area
values
0-3A 1A
0-30A 10A
0-3A 0.1A
0-30A 1A
0-3A 0.01A
0-30A 0.1A
0-3A 0.001A
0-30A 0.01A
SV
SV
Short
V
C
D
W
A
Resistance
stepping values
Area
0.1-10Ω
10-99Ω
100-999Ω
1000-4000Ω
0.1-10Ω
10-99Ω
100-999Ω
1000-4000Ω
0.1-10Ω
10-99Ω
100-999Ω
1000-4000Ω
0.1-10Ω
10-99Ω
100-999Ω
1000-4000Ω
Prog CC
CV
30A
CR
OFF
Shift
Stepping
values
1Ω
10Ω
100Ω
1000Ω
0.1Ω
1Ω
10Ω
100Ω
0.01Ω
0.1Ω
1Ω
10Ω
0.001Ω
0.01Ω
0.1Ω
1Ω
