- Page 1 Edge Awning OWNER'S MANUAL ™...
- Page 2 Resources Required Fabric Care Introduction The Edge Awning features an internal motor to steadily operate the awning. The awning also features adjustable pitch arms and optional Serenity lighting. Safety Read and understand all instructions before operating this product. Adhere to all safety labels This manual provides general instructions.
- Page 3 Moving parts can pinch, crush or cut. Keep clear and use caution. Operation The following instructions provide general operation of the Edge Awning. However, some units may not use the LCI switch (Fig. 1). Extending the Awning Verify the unit's battery is fully charged and connected to the electrical system.
- Page 4 NOTE: Extension is considered complete when the fabric is completely unrolled, the valance polycord is visible and a section of the roll tube is exposed. (Fig. 2). Fig. 2 Fabric Fabric Polycord Roll Tube Awning Head Valance Exposed Roll Tube Section NOTE: The awning fabric should always be above the roll tube.
- Page 5 Slide the pitch arm (Fig. 4A) up to the desired position. Tighten the knob (Fig. 4B) on the underside of the pitch arm to secure in the desired position. Fig. 4 Retracting the Awning NOTE: The awning must be in the flat position prior to retracting the awning. If the pitch arm has been set, loosen the knobs (Fig.
- Page 6 Manual Override In the event of power loss or motor failure, the awning can be extended and retracted manually. Perform the following procedure to manually retract the awning. NOTE: This procedure may also be performed to extend or retract the awning in the event of dry camping or camping without a battery.
- Page 7 Maintenance Resources Required • 5 gallon bucket • cup of dish soap • Clean water Fabric Care Over-spray of cleaning solution can cause eye and sensitive skin irritation. Flush affected area with clean water and seek medical attention, if necessary. Wear eye protection and appropriate protective clothing to avoid personal injury.
- Page 8 The contents of this manual are proprietary and copyright protected by Lippert Components, Inc. (“LCI”). LCI prohibits the copying or dissemination of portions of this manual unless prior written consent from an authorized LCI representative has been provided. Any unauthorized use shall void any applicable warranty. ...
