- Page 1 Solera 3000WS Series ® Awning (Wind Sensor) OEM INSTALLATION MANUAL...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Introduction Safety Prior To Installation Resources Required Installation Awning Rail Installation (If Needed) Awning Installation Securing the Fabric Awning Wiring OEM Syncing the Bluetooth Wind Sensor to the Lippert Unity Board for the One Control App Pairing Tool Requirements VIN and QR Scanning Troubleshooting Seal Wall Penetrations... -
Page 3: Safety
Awning in any other manner than described may result in personal injury, damage to the unit or the awning assembly as well as voiding the Lippert Components Limited Warranty. Always wear eye protection when performing service, maintenance or installation procedures. -
Page 4: Installation
Installation Awning Rail Installation (If Needed) NOTE: Awning rail not included. Position the awning rail along the line where the roof and wall meet or: For pitched awnings: A minimum of 6” above doors or windows For flat awnings: A minimum of 4” above doors or windows NOTE: The awning rail MUST be level and parallel with the floor line of the unit (Fig. - Page 5 Insert the drive head assembly shaft into end cap (Fig. 3). Align the holes and secure with waxed screw. Repeat process for idler head assembly at opposite end of roll tube. NOTE: Keep the head of the wax screw 1/8" from being fully fastened to avoid compromising the structural integrity of the wax screw.
-
Page 6: Securing The Fabric
Lift the support arm assembly up and secure by setting the awning assembly to the desired height and attaching it to the side of the unit with two #14 x 1 ” screws at the top (Fig. 5) and two #14 x 1 ”... -
Page 7: Awning Wiring
Awning Wiring Solera Power Awning motors come stock with an internal 6A auto reset breaker. If this breaker trips, it will take approximately 30 seconds to reset. Lippert recommends the awning be wired into a 15A circuit breaker. All wire shall be 14 AWG or higher as necessary to provide 11.5V minimum at all times to the Lippert supplied power cable connection. -
Page 8: Pairing Tool Requirements
Pairing Tool Requirements For pairing at the OEM Plant, Lippert developed an OEM Pairing Tool which allows a team member to quickly pair Lippert Bluetooth accessories. • The OEM Pairing Tool app that works with Android devices with OS of 8 or higher. •... -
Page 9: Troubleshooting
Fig. 13 Fig. 14 Troubleshooting If an error occurs during pairing, you will see a red explanation next to the device name (Fig. 15). Click on the error icon, you will get either of the pop-up notifications Connecting Error (Fig. 16) or Paring Error (Fig. -
Page 10: Seal Wall Penetrations
Seal Wall Penetrations Seal all fastener locations and wire penetrations with silicone sealant to protect against water intrusion (Fig. 19). Reinstall all wire covers onto the support arm assemblies. Fig. 19 Operation When ON, the automatic retraction due to wind feature will operate without any other inputs. If people are between the awning arm and the frame, they will be injured. - Page 11 From the Main Menu, tap the + icon (Fig. 20A) in the upper right corner. Select Awning Sensor (Fig. 21A) from the list of devices to add or manage. Fig. 20 Fig. 21 There are two ways to connect. You can either scan the QR code on the label (Fig. 22A), which is located on the front of the drive side of the awning arm, the label in your Owner's Manual or the label on the actual wind sensor inside the awning arm or enter the 12 digit MAC address (Fig.
-
Page 12: Extending And Retracting The Awning Using The Onecontrol App
Tap either Scan with Camera (Fig. 23A), or Connect Manually (Fig. 23B). Either scan the QR code or type in the MAC Address (Fig. 23C). The awning will now appear in the OneControl menu. It may be visible under Modes (Fig. 23D). Fig. -
Page 13: Settings For Automatic Retraction Due To Wind Events
Settings for Automatic Retraction Due to Wind Events To set a wind sensitivity level, tap the arrow (Fig. 26A) in the Awning Sensor cell on the home screen and use the slider (Fig. 26C) to adjust the wind sensitivity level, or to toggle the automatic retraction due to wind events on or off (Fig. -
Page 14: Extending The Awning With The Power Button Switch
Extending the Awning with the Power Button Switch NOTE: Some units may not use the Lippert switch (Fig. 27). Verify the unit battery is fully charged and connected to the electrical system. NOTE: if the unit is equipped with a locking latch, be sure to unlock the latch prior to extending the awning. Press and hold EXTEND (Fig. -
Page 15: Adjusting Pitch - All Solera Awnings
During incidents of high wind, heavy rain or extended time away from the unit, it is advisable to retract the awning completely to prevent damage to the awning and the Unit. Adjusting Pitch - All Solera Awnings NOTE: The awning will pitch itself to purge the pooling of excess water and may dump a significant amount of water without notice. -
Page 16: Troubleshooting
Troubleshooting Manual Override In the event of power loss or motor failure, the awning can be extended or retracted manually. Perform the following procedure to manually extend or retract the awning. NOTE: This procedure may also be performed to extend or retract the awning in the event of dry camping or camping without a battery. -
Page 17: Troubleshooting Adjusting Pitch - All Solera Awnings
Troubleshooting Adjusting Pitch - All Solera Awnings NOTE: If the articulating arm does not hold position, it can be tightened by adjusting the bolt (Fig. 34A) in the center of the articulating arm. Fig. 34 NOTE: When tightening the bolt do not tighten more than 1/4 turn at a time and do not tighten to the point of crushing the pitch arm. -
Page 18: Wiring Diagram
Wiring Diagram *Ground Awning Motor *Awning LED Lights *Awning LED Light Switch *Awning LED light strip *LED light switch and extend or connects to a retract rocker switch connect 5amp latching to the configurable input output on connector on the Unity Control. Unity Control. -
Page 19: Notes
Notes Page 19 Rev: 01.17.23 CCD-0007001... - Page 20 The contents of this manual are proprietary and copyright protected by Lippert. Lippert prohibits the copying or dissemination of portions of this manual unless prior written consent from an authorized Lippert representative has been provided. Any unauthorized use shall void any applicable warranty. The information contained in this manual is subject to change without notice and at the sole discretion of Lippert. ...
