System and Safety Information The Solera Classic Awning is designed for use on most recreational vehicle units and is available in a variety of sizes to fit even the largest unit. Additional information about this product can be obtained from www.
Operation Fig. 1 Channel Extending the Awning Channel Locking Make sure the black locking knobs on the Knob mount/rafter arm upper channel (channel #3) Channel (Fig. 1) are loosened and pinch the travel locks together to release the outer arm from the mount/rafter arm.
Fabric Replacement Fabric Removal Remove the drip cap (if equipped) from the end the fabric will be removed from. Remove the #6 x 1/2” hex head screws located on the awning rail (2 total). Set screws aside. Extend the awning out completely by sliding the mount/rafter arms all the way to the top of the outer arm and make sure they lock into place and insert cotter pins (Fig.
Place the removed assembly onto a level area. Have someone securely hold the idler head and roll tube. 10. Hold the drive head assembly securely (there will be tension to be released) and remove the drive head assembly cotter pin. Failure to maintain control of the roll tube, fabric and drive/idler head may result in serious injury or property damage.
Page 6
Using the three screws previously removed from the end caps, attach the drive head assembly to the roll tube, making sure the orientation is the same. NOte: Be sure the drive head assembly with the cam lock is on the right-hand side of the awning. Secure the idler head and roll tube.
Page 7
Solera Classic Awning troubleshooting What's Happening? What Should Be Done? Check position of the cam lock (roll out). Ensure that the travel locks have been released from the outer arm. Awning will not extend. Make sure the locking knob for the rafters has been loosened.
Maintenance - Solera Awnings Fabric Care NOte: If the awning is retracted while wet, extend the awning and let it dry as soon as conditions allow before retracting. This will help prevent the formation of mildew and add greatly to the life of the awning.
White Idler Arm Assembly (Short Idler Arm 52") 346903 Black Idler Arm Assembly (Short Idler Arm 52") 346893 Kit Accessory Classic Manual Awning Page 10 of 14 Contact us: Lippert Components Inc. - www.lci1.com/support - Phone: (574) 537-8900 - Email: customerservice@lci1.com Rev: 06.05.2018...
Page 11
Black Drive Arm Assembly (Universal Drive Arm 58") 362112 White Idler Arm Assembly (Universal Idler Arm 58") 362114 Black Idler Arm Assembly (Universal Idler Arm 58") Page 11 of 14 Contact us: Lippert Components Inc. - www.lci1.com/support - Phone: (574) 537-8900 - Email: customerservice@lci1.com Rev: 06.05.2018...
Page 12
Black Drive Arm Assembly (Long Drive Arm 60") 346905 White Idler Arm Assembly (Long Idler Arm 60") 346907 Black Idler Arm Assembly (Long Idler Arm 60") Page 12 of 14 Contact us: Lippert Components Inc. - www.lci1.com/support - Phone: (574) 537-8900 - Email: customerservice@lci1.com Rev: 06.05.2018...
Page 13
Fasten Screw #10 - 16 x 1 " 298760 Cotter Hairpin 347119 Fasten Pin 1/8 x 3 Cotter ZN 431664 Spacer - AM Classic Page 13 of 14 Contact us: Lippert Components Inc. - www.lci1.com/support - Phone: (574) 537-8900 - Email: customerservice@lci1.com Rev: 06.05.2018...
Page 14
The contents of this manual are proprietary and copyright protected by Lippert Components, Inc. (“LCI”). LCI prohibits the copying or dissemination of portions of this manual unless prior written consent from an authorized LCI representative has been provided. Any unauthorized use shall void any applicable warranty. ...
