Do you have a question about the Solera and is the answer not in the manual?

Questions and answers

L Strickland
March 23, 2025

The factory installed Solera 3000 motor driven awning was installed on metal "cage" supports inside the fiberglass outside wall. Unfortunately, we have discovered that the awning is a total of 1" too wide for the installed channel bracket, causing the outer arm to rub against the mounting bracket. Remounting one of the arm assemblies is not an option because of the internal steel "stud" locations. Is it possible to re-position the shaft internal to the roller? Is there a better option?

0

Related Manuals for Lippert Components Solera

Summary of Contents for Lippert Components Solera

  • Page 1 Solera Power Awning OWNER'S MANUAL ®...

  • Page 2: Table Of Contents

    Notes System Information The Solera® Power Awning features an internal motor to steadily operate the awning. Additionally, the friction joint allows for rain dump and adjustable pitch features, and there is no rafter arm to lock in place. The friction joint also provides added stability.

  • Page 3: Operation

    NOTe: This latch is optional and may or may not be installed on one or both support arms. Fig. 1 Fig. 4 - Complete extension Fig. 3 Fabric Valance Seam Roll Tube Fig. 2 exposed Roll Valance Tube Section Awning Head Rev: 06.01.2018 Page 3 Solera® Power Awning Owner's...

  • Page 4: Adjusting Pitch - All Solera Awnings

    Adjusting Pitch - All Solera Awnings NOTe: The awning will pitch itself to purge the pooling of excess water and may dump a significant amount of water without notice. Pitch can be set by adjusting the articulating arm to tip one side of the awning to allow water runoff.

  • Page 5: Troubleshooting

    During incidents of high wind, heavy rain or extended time away from the unit, it is advisable to retract the awning completely to prevent damage to the awning and the RV. Fig. 7 Fig. 8 Rev: 06.01.2018 Page 5 Solera® Power Awning Owner's...

  • Page 6: Solera Power Awning Assembly

    SOLERA POWER AWNING ASSEMBLY AWNINGS Idler Head Assembly Fabric Awning Rail Drive Head Assembly Roll Tube end Cap Support Arm Assembly Page 6 of 16 Contact us: Lippert Components Inc. - www.lci1.com/support - Phone: (574) 537-8900 - Email: customerservice@lci1.com Rev: 06.01.2018...

  • Page 7: Solera Power Awning Components

    Part # Description 281928 White Awning Rail (144") 281929 Black Awning Rail (144") 2661301 White End Caps 2661302 Black End Caps Page 7 of 16 Contact us: Lippert Components Inc. - www.lci1.com/support - Phone: (574) 537-8900 - Email: customerservice@lci1.com Rev: 06.01.2018...
  • Page 8 White Drive Head Front Cover 289560 Black Drive Head Front Cover 289558 White Drive Head Rear Cover 289561 Black Drive Head Rear Cover Page 8 of 16 Contact us: Lippert Components Inc. - www.lci1.com/support - Phone: (574) 537-8900 - Email: customerservice@lci1.com Rev: 06.01.2018...
  • Page 9 .500" 20 PA 16 DP, CLR ZN GEAR 353964 266142 Bushing (Only available 266143 Bushing as a kit) 281828 Bushing 266137 E-Clip " 276160 E-Clip " Page 9 of 16 Contact us: Lippert Components Inc. - www.lci1.com/support - Phone: (574) 537-8900 - Email: customerservice@lci1.com Rev: 06.01.2018...
  • Page 10 PNH SMS ZN SQ AB ST, BLK HD 266132 Screw IHWH 2N SLF ST ( - 20 x ") (Motor-to-mount) Page 10 of 16 Contact us: Lippert Components Inc. - www.lci1.com/support - Phone: (574) 537-8900 - Email: customerservice@lci1.com Rev: 06.01.2018...
  • Page 11 Rubber Grommet (for Manual Override Opening) 289373 White Awning Center Support Assembly 289374 Black Awning Center Support Assembly NOTe: Only required for Solera Awnings greater than 21' in length. 293659 White Switch Kit 12GA Wire Harness 293658 Black Switch Kit 12GA Wire Harness...
  • Page 12 Gas Strut; 124 - 144 lbs (for Pitched Arm Assemblies) 1/4") 348108 Screw (#14 - 10 x 1 (Arms-to-Coach) 282484 Star Washer (for Gas Strut) Page 12 of 16 Contact us: Lippert Components Inc. - www.lci1.com/support - Phone: (574) 537-8900 - Email: customerservice@lci1.com Rev: 06.01.2018...
  • Page 13 Black Switch Only 285079 White Bezel Spacer 285077 Black Bezel Spacer 373008 Power Feed Wires 273007 Power Feed, 2 Way Page 13 of 16 Contact us: Lippert Components Inc. - www.lci1.com/support - Phone: (574) 537-8900 - Email: customerservice@lci1.com Rev: 06.01.2018...
  • Page 14 White Wire Cover; 21"; Wide 2661391872 Black Wire Cover; 21"; Wide 266139429 White Wire Cover; 26.75"; Wide 2661391964 Black Wire Cover; 26.75"; Wide Page 14 of 16 Contact us: Lippert Components Inc. - www.lci1.com/support - Phone: (574) 537-8900 - Email: customerservice@lci1.com Rev: 06.01.2018...

  • Page 15: Notes

    Notes Rev: 06.01.2018 Page 15 Solera® Power Awning Owner's...
  • Page 16 The contents of this manual are proprietary and copyright protected by Lippert Components, Inc. (“LCI”).  LCI prohibits the copying or dissemination of portions of this manual unless prior written consent from an authorized LCI representative has been provided.  Any unauthorized use shall void any applicable warranty. ...
