Toro Workman GTX Series Operator's Manual page 6

139-4610
1. Warning—read the
Operator's Manual.
1. Lights—On
2. Lights—Off
3. Raise the bed.
4. Lower the bed.
140-4590
1. Read the Operator's Manual for battery information.
decal139-4610
2. Crushing hazard, cargo
box—use the prop rod to
support the cargo bed.
decal140-4590
12V
140-2487
1. Read the Operator's
Manual for fuse
information.
2. Display (2 A); fuse located
under the hood.
3. Power (10 A)
4. Bed lift (15 A)
5. Electric relay (20 A)
140-4584
5. Warning—read the Operator's Manual.
6. Warning—receive proper training before operating the
machine.
7. Falling hazard; severing hazard of limbs—do not carry
passengers in the bed; do not carry extra passengers in
between the seats; do not put your arms or legs outside of
the machine while operating.
8. Tipping hazard—drive slowly across or up slopes; take turns
slowly; do not exceed speeds of 25 kph (16 mph); drive slowly
when hauling cargo; drive slowly on uneven terrain.
6
48V
10A 15A 5A
2A
20A 30A 15A
140-2487
6. Horn (30 A)
7. USB power point (5 A)
8. Headlights (10 A)
9. Electric power (less than
or equal to 15 A)
12V
10A
decal140-2487
decal140-4584
