EN
COMFORT CONTROL
User's manual
Manufacturer: AUTOTERM LLC
Paleju 72, Marupe, Latvia, LV-2167
Warranty Department
warranty@autoterm.com
Technical Support
service@autoterm.com
www.autoterm.com
v10.2020

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the COMFORT CONTROL and is the answer not in the manual?

Questions and answers

Related Manuals for AUTOTERM COMFORT CONTROL

Summary of Contents for AUTOTERM COMFORT CONTROL

  • Page 1 COMFORT CONTROL User’s manual Manufacturer: AUTOTERM LLC Paleju 72, Marupe, Latvia, LV-2167 Warranty Department warranty@autoterm.com Technical Support service@autoterm.com www.autoterm.com v10.2020...

  • Page 2: Table Of Contents

    CONTENTS CONTENTS ..........................2 INTRODUCTION .......................... 3 SAFETY INSTRUCTIONS ......................3 LIABILITY ............................. 4 GENERAL INFORMATION ....................5 1.1. DISPLAY........................5 1.2. ROTARY KNOB ......................6 1.3. BACK BUTTON ......................6 1.4. QUICK BUTTON ......................6 1.5. LED INDICATORS ......................6 MOUNTING AND CONNECTION..................

  • Page 3: Introduction

    Thank You for choosing control panel AUTOTERM Comfort Control! We are doing everything to make this product meet Your requirements, so its quality satisfies every customer. Comfort Control is designed to be intuitive and comfortable to use, to ensure the best experience when it comes to controlling Your climate.

  • Page 4: Liability

    The heater can be switched on again 15-20 seconds after disabling indications on the control panel, which means that the heater has shut down. Personnel certified by AUTOTERM is needed In case of faults in the operation of the heater, contact specialized repair organizations authorized by AUTOTERM.

  • Page 5: General Information

    1. GENERAL INFORMATION 1. DISPLAY 3. BACK BUTTON 5. LED INDICATORS 2. ROTARY KNOB 4. QUICK BUTTON 1.1. DISPLAY • While in sleep mode: o display is inactive; o screensaver shows: ─ temperature; ─ current time and date; ─ set operation mode, if active. Control panel goes in to sleep mode after the time of inactivity set in display settings.

  • Page 6: Rotary Knob

    When an operation mode is active, respective symbol is displayed on the main screen (under the current time) and it works as a quick menu. By rotating the knob three options can be accessed: • Active operation mode • Shut off the heater •...

  • Page 7: Mounting And Connection

    When connected to the power supply control panel turns on automatically. When turned on LED indicators light up, while showing AUTOTERM logos on the display. Connection process takes approx. up to 20 seconds. If connection is established display shows main screen.

  • Page 8: Operation And Settings

    3. OPERATION AND SETTINGS 3.1. MAIN MENU Main menu can be accessed from main screen by pressing the rotary knob once. Navigate through the menu by turning the knob. To enter the selected menu, press the knob once. TIMERS Is used to set and enable/disable up to 3 timers. Is used to set different heating modes, depending on the HEATING connected heater.
  • Page 9 Editing the timer Set the time of day for heater to start: • Set hours and confirm; • Set minutes and confirm. Set working duration of the heater. Duration can be set from 30min to 720min* with increasing step of 5min.

  • Page 10: Heating

    3.3. HEATING In “Heating” menu different operation modes for heating can be set, depending on the connceted heater. To set heater modes select the “Heating” menu from the main menu by pressing the knob once and then select one of the heating modes: Temperature can be set in a range from 0°C up to 30°C, with step of 1°C.
  • Page 11 Setting Power mode Select “Power mode” from the menu. Set power level and confirm. Set work time and confirm. When mode is active, respective symbol is shown on the main screen Setting Heat + Ventilation mode Select “Heat + Ventilation” from the menu. Set temperature and confirm.

  • Page 12: Ventilation

    • 20min up to 12h; • after 12h next step is ∞. AUTOTERM FLOW liquid heaters and AUTOTERM AIR 8D air heater does not support ventilation mode! It is impossible to switch to ventilation mode while heater is operating in one of the...

  • Page 13: Settings

    Setting Ventilation mode Set power level and confirm. Set work time and confirm. When mode is active, respective symbol is shown on the main screen 4. SETTINGS In the “Settings” menu general settings for control panel and advanced settings for the heater can be changed. Available settings are displayed depending on the connected heater.

  • Page 14: Pre-Heater (For Liquid Heaters)

    • ADVANCED – change advanced settings of the heater: o SHUTDOWN – set voltage and time for battery protection. VOLTAGE If the actual voltage of the power supply is lower than the set voltage for the set duration, heater shuts down and operation modes cannot be activated.

  • Page 15: Led

    o FAN – set and enable/disable activation of the interior fan. Set coolant temperature at which interior fan of the vehicle will activate. Temperature can be set in rage a of 30°C to 60°C. Default value is 40°C. To activate the “Fan” function, after enabling it, heater must be disconnected and reconnected from the power supply.

  • Page 16: Faults And Errors

    Failure to do so may lead to premature failure of the heater. That is why AUTOTERM Comfort Control has a built-in reminder to start the heater for 30 minutes, if it has been out of operation for at least 30 days.
