Terminal diagrams:
7.1.
Central lubrication pump EP-1 and FKGGM-EP without control unit:
+
- (Ground)
7.2.
Central lubrication pump EP-1 without control unit:
Special model with bayonet connector:
+
- (Ground)
(PIN ...) = Assignement of the line socket
blue
brown
blue (PIN 1)
brown (PIN 2)
BEKA 2016 All rights reserved!
