PowerBox Systems iGyro SRS Instruction Manual page 26

7. Specification
Operating voltage:
Current drain, iGyro:
Current drain, GPS:
Maximum current:
Receiver:
RC systems supported:
Gyro sensor type:
Number of sensor axes:
Gyro regulation modes:
Channels:
Servo outputs:
Servo signal resolution:
Servo frame rate:
Screen:
Dimensions:
Weight incl. GPS sensor:
Temperature range:
EMV approval:
CE approval:
4.0 V - 9.0 V
51 mA
approx. 60 mA
min. 10 A
Two, using serial inputs
Spektrum SRXL, DSM2 / DSMX,
Futaba, HOTT, M-Link, Jeti
MEMS
3
Heading mode, Normal mode
18
5
0.5 μs
18 ms
Graphic OLED, 128 x 64 pixels
52 x 35 x 14 mm
50 g
-30°C to +75°C
EN 55014-1:2006
2004/108/EG
-26-
