4.6. Flächentyp einstellen
When the Test Fly Assistant is complete, the set-up procedure for the
gyro is finished!
5. Experts and manual adjustments
All parameters established using the Setup Assistant can also be
adjusted manually. The system offers a whole series of additional
adjustment options to cater for particular set-ups, such as thrust vector
control systems. It is also possible to adjust the gyro characteristics and
flight modes individually. The following section explains the menu points
and functions available.
5.1. The installed orientation of the iGyro
This setting can be found in the GENERAL SETTINGS menu. To simplify
the process of installing and operating the system, the iGyro must be
informed once of the unit's orientation in the model after it has been
installed. This procedure makes it possible to use the terms AILERON,
ELEVATOR and RUDDER subsequently in the GYRO SETTINGS menu.
SCREEN refers to the position of the OLED screen in the model; SWITCH
refers to the SensorSwitch socket.
Once you have installed the system in the model, you must enter the
position of the screen and the position of the switch. There are six possible
options for the screen and switch locations.
