NOTICE TO INSTALLER: Instructions must remain with installation.
Product information presented
here reflects conditionso at time of
publication. Consult factory regarding
discrepancies or inconsistencies.
Through research and development, design, testing and manufacturing, we have been able to bring products to the market that
solve problems that plague consumers, industry, and the environment. This commitment to our customers has enabled them to enjoy
returns of our joint efforts.
1. Inspect your unit. Occasionally, products are damaged during shipment. If the unit is damaged, contact your dealer before using.
DO NOT remove the test plugs in the cover nor the motor housing.
2. Carefully read the literature provided to familiarize yourself with specific details regarding installation and use. These materials
should be retained for future reference.
SEE BELOW FOR LIST OF WARNINGS
1. To reduce the risk of electrical shock, a properly grounded
receptacle of grounding type must be installed and protected
by a ground fault circuit interrupter (GFCI) and in accordance
with national electrical code and local codes.
2. Make certain that the receptacle is within the reach of the
pump's power supply cord. DO NOT USE AN EXTENSION
CORD. Extension cords that are too long or too light do
not deliver sufficient voltage to the pump motor. But more
important, they could present a safety hazard if the insulation
were to become damaged or the connection end were to fall
into the sump.
3. Testing for Ground. As a safety measure, each electrical
outlet should be checked for ground using an Underwriters
Laboratory Listed circuit analyzer which will indicate if the
power, neutral and ground wires are correctly connected to
your outlet. If they are not, call a qualified electrician.
4. For electrical safety, it is recommended that a GFCI be
installed.
5. FOR YOUR PROTECTION, ALWAYS DISCONNECT PUMP
FROM ITS POWER SOURCE BEFORE HANDLING. Single
phase pumps are supplied with a 3-prong grounded plug to
help protect you against the possibility of electrical shock.
DO NOT, UNDER ANY CIRCUMSTANCES, REMOVE
THE GROUND PIN. To reduce the risk of electrical shock,
a properly grounded receptacle of grounding type must be
installed and protected by a ground fault circuit interrupter
(GFCI) in accordance with national electrical code and local
codes.
6. Installation and checking of electrical circuits and hardware
should only be performed by a qualified licensed electrician.
7. Risk of electric shock - These pumps have not been
investigated for use in swimming pool and marine areas.
8. According to the state of California (Prop 65), this product
contains chemicals known to the state of California to cause
cancer and birth defects or other reproductive harm.
95 N. Oak St. • Kendallville, IN 46755
Model S1108
CRAWL SPACE
PREINSTALLATION CHECKLIST
© Copyright 2015 Star Water Systems. All rights reserved.
S
TAR
®
PUMPING SYSTEM
®
SEE BELOW FOR LIST OF CAUTIONS
1. Check to be sure your power source is adequate for handling
the voltage requirements of the motor, as indicated on the
pump or basin plate.
2. Make sure the pump electrical supply circuit is equipped
with fuses or circuit breakers of proper capacity. A separate
branch circuit is recommended, sized according to the
National Electrical Code for the current shown on the pump
name plate.
3. Pump should be checked frequently for debris and/or build
up which may interfere with the float "on" or "off" position.
Repair and service should be performed by an Authorized
Service Station only.
4. A CHECK VALVE MAY BE REQUIRED TO REDUCE
UNNECESSARY CYCLING OF PUMP.
5. Dewatering pumps are not designed or intended for handling
raw sewage.
6. Maximum operating temperature for Crawl Space Drain
Pumps must not exceed 130°F (54°C).
NOTE: Pumps with the "UL" mark and pumps with the "US"
mark are tested to UL Standard UL778. CSA Certified
pumps are certified to CSA Standard C22.2 No. 108.
1
CAUTION
REFER TO WARRANTY PAGE 2.
FW0131
0415
Supersedes
0202

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the S1108 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Star S1108

  • Page 1 8. According to the state of California (Prop 65), this product REFER TO WARRANTY PAGE 2. contains chemicals known to the state of California to cause cancer and birth defects or other reproductive harm. © Copyright 2015 Star Water Systems. All rights reserved.
  • Page 2: Limited Warranty

    DO NOT ever cut, splice or damage power cord. DO NOT carry or lift pump by its power cord. DO NOT use an extension cord with this Crawl Space Pumping System. © Copyright 2015 Star Water Systems. All rights reserved.
  • Page 3: Performance Characteristics

    Performance Characteristics PUMP PERFORMANCE CURVE GALLONS LITERS FLOW PER MINUTE IL1842 Feet Meters Gal. Liters Shut-off Head: 19.25 ft. (5.9m) © Copyright 2015 Star Water Systems. All rights reserved.
  • Page 4 "SLOTTED" BASIN WALL OR WEEP TILES DETAIL "A" SK1802 Figure 2A.2 EXTENSION 38 1/8" GROUND LEVEL COMPLETE INSTALLATION OF DRAIN LINES OR WEEP TILES 20" "SLOTTED" BASIN SK1801 SK1803 Figure 2A.1 Figure 2A.3 © Copyright 2015 Star Water Systems. All rights reserved.
  • Page 5 DRAIN LINES OR WEEP TILES 25' CORD DISCHARGE LINE GROUND LEVEL BACKFILL DRAIN LINES OR GRAVEL BACKFILL WEEP TILES "SLOTTED" BASIN GRAVEL "SLOTTED" BASIN PRIMARY PUMP PRIMARY PUMP Figure 4.1 Figure 4.2 SK1807 © Copyright 2015 Star Water Systems. All rights reserved.
  • Page 6: Freezing Protection

    Note: If there is the possibility of the discharge line freezing, then install the discharge line as recommended in Figure 6.1. GROUND FROST LINE DISCHARGE LINE PIPING BACKFILL GRAVEL Figure 6.1 SK1822 © Copyright 2015 Star Water Systems. All rights reserved.
  • Page 7: Replacement Parts List

    10-0786 Extension Kit and Lid 10-0770 Weather Tight Junction Box 10-1494 Alarm PUMP VARIABLE LEVEL FLOAT SWITCH ALARM PANEL "SLOTTED" BASIN SK1858 SK1824 WEATHER TIGHT EXTENSION KIT JUNCTION BOX AND LID © Copyright 2015 Star Water Systems. All rights reserved.
  • Page 8: Troubleshooting Guide

    Under flooded conditions, contact your local electric company or a qualified licensed electrician for disconnecting electrical service prior to pump removal. © Copyright 2015 Star Water Systems. All rights reserved.
