SUBMERSIBLE SUMP PUMP MODELS 2SPHALC, 3USPHC, 5USPHC, 423815, 433055 Español p. 9 ATTACH YOUR RECEIPT HERE Purchase Date Questions, problems, missing parts? Before returning to your retailer, call our customer service department at 1-800-742-5044, 7:30 a.m. - 5:00 p.m., EST, Monday - Friday.
Page 2
PACKAGE CONTENTS 5-1/2-in 12-in 8.5-in DESCRIPTION QUANTITY WIDTH HEIGHT CORD LENGTH Pump 8-1/2 in. 12 in. 9 ft. SAFETY INFORMATION Please read and understand this entire manual before attempting to assemble, operate, or install the product. NOTE: This product is Listed to applicable standards and requirements by UL Solutions. CSA certified pumps are certified to CSA Standard C22.2 No.
Page 3
• ELECTRICAL SHOCK ALERT. Connect this product to a properly-grounded 115 volt circuit equipped with a Ground Fault Circuit Interrupter (GFCI) device. Make sure the electrical supply circuit is equipped with fuses or circuit breakers with a minimum capacity of 15 amps. •...
This sump pump is intended for use in indoor sump pits only. GFCI CHECK VALVE Approximate pump On / Off levels from base of pump VENT HOLE Float Models 2SPHALC, 433055, Switch 3USPHC, 423815, 5USPHC On Level 15.5” Off Level 6.25”...
INSTALLATION INSTRUCTIONS 1. Make sure the sump basin is cleared of any debris or sediment, then place the sump pump on a hard surface inside the basin. 22 in. 12 in. IL2048 2. Connect the discharge pipe, fittings, and check 1-1/2-in Discharge pipe valve (not provided) to pump discharge.
Page 6
INSTALLATION INSTRUCTIONS 4. Make sure your hands are dry and you are 115 V not standing in water. Connect the pump to a GFCI Outlet properly-grounded GFCI electrical outlet. WARNING: Do not use an extension cord. NOTE: Tape the electrical cord to the discharge pipe to prevent it from interfering with the motion of the float.
CARE AND MAINTENANCE WARNING: Always disconnect pump from power source before handling. Remove debris At least every three months: Remove any debris that may build up in the sump basin to prevent it from interfering with the operation of the float switch. Clean out the vent hole that was drilled in the Clean discharge pipe during installation.
PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION Pump runs 1. Float is stuck in the ‘on’ position. 1. Make sure the float can move continuously. freely. 2. Float switch is defective. 2. Replace pump. Pump runs but 1. Pump is air-locked. 1. Clean out vent hole in discharge delivers little pipe.
Page 9
BOMBA DE SUMIDERO SUMERGIBLE MODELOS 2SPHALC, 3USPHC, 5USPHC, 423815, 433055 ADJUNTE SU RECIBO AQUÍ Fecha de compra ¿Preguntas, problemas, piezas faltantes? Antes de volver a la tienda, llame a nuestro Departamento de Servicio al Cliente al 1-800-742-5044, de lunes a viernes de 7:30 a.m. a...
Page 10
CONTENIDO DEL PAQUETE 5-1/2-in 12-in 8.5-in DESCRIPCIÓN CANTIDAD ANCHO ALTURA LONGITUD DEL CABLE Bomba 8-1/2 pulg. 12 pulg. 9 pies INFORMACIÓN DE SEGURIDAD Lea y comprenda completamente este manual antes de intentar ensamblar, usar o instalar el producto. NOTA: Este producto está homologado conforme a las normas y requisitos aplicables por UL Solutions.
Page 11
que el circuito de suministro eléctrico esté equipado con fusibles o interruptores de circuito con una capacidad mínima de 15 amperios. • ALERTA DE DESCARGA ELÉCTRICA. Nunca utilice una extensión eléctrica. • ALERTA DE DESCARGA ELÉCTRICA.Estas bombas se suministran con un enchufe de 3 clavijas con puesta a tierra para ayudar a protegerlo contra la posibilidad de descargas eléctricas.
Page 12
PREPARACIÓN Tiempo de instalación estimado: 20 minutos Materiales necesarios para en ensamblaje: recipiente para sumidero, tubería de entrada, tubería de descarga (PVC, polietileno o acero galvanizado), válvula de retención y sistema de adhesivo para PVC de 2 pasos (cebado y sellado). Herramientas necesarias para el ensamblaje: llave para tuberías y sierra.
INSTRUCCIONES DE INSTALACIÓN 1. Asegúrese de que el recipiente del sumidero esté libre de suciedad y sedimentos y luego coloque la bomba de sumidero sobre una superfi cie dura dentro del recipiente. 55,88 cm 30,48 cm IL2048 2. Conecte la tubería de descarga, los conectores Tubo de descarga y y la válvula de retención (no se incluye) a la conectores de 1-1/2 pulg.
Page 14
INSTRUCCIONES DE INSTALACIÓN 4. Asegúrese de tener las manos secas y de no Tomacorriente con estar parado sobre agua. Conecte la bomba a interruptor de circuito un tomacorriente con interruptor de circuito de de falla de puesta falla de puesta a tierra (GFCI) con la debida a tierra de 115 V puesta a tierra.
CUIDADO Y MANTENIMIENTO ADVERTENCIA: siempre desconecte la bomba de la fuente de alimentación antes de manipularla. Elimine los desechos Al menos cada tres meses: Elimine cualquier desecho que pueda haberse acumulado en el recipiente del sumidero para evitar que interfieran con el funcionamiento del interruptor del flotador.
PROBLEMA CAUSA POSIBLE ACCIÓN CORRECTIVA La bomba funciona 1. El flotador está atascado en la posición ‘on’ 1. Asegúrese de que el flotador pueda de manera (encendido). moverse libremente. continua. 2. El interruptor del flotador está defectuoso. 2. Reemplace la bomba. La bomba funciona 1.
