Accessories
Table 1: Accessories and Replacement Parts (Order Separately)
Code Number Description
DMPR-KC003 7 in. (178 mm) Blade Pin Extension (without bracket) for Johnson Controls® Direct-Mount Damper
Applications (quantity 1)
Note: Available with damper and may be ordered separately
Weathershield Kit for Damper Application of M9203, M9308, and M9310 Series Electric Actuators
M9000-322
(quantity 1)
M9000-400 Jackshaft Linkage Adapter Kit (quantity 1)
M9000-560 Ball Valve Linkage Kit for applying M9104, M9203, and M9208 Series Electric Actuators to VG1000 Series
Valves (quantity 1)
M9000-561 Thermal Barrier Kit for M9000-560 Ball Valve Linkage. Extends M(VA)9104, M(VA)9203, and M(VA)9208
Series Electric Spring Return Actuators applications to include low pressure steam (quantity 1)
M9000-604
Replacement Anti-Rotation Bracket Kit for M9203, M9208, M9220, M9308, M9310, M9320, and M9335
Series Electric Actuators (quantity 1)
M9000-606 Position Indicator for Damper Applications (quantity 5)
M9000-607 Position Indicator for VG1000 Series Ball Valve Applications (quantity 5)
M9203-100 Remote Mounting Kit with Crankarm Kit (quantity 1)
M9203-110 Universal Mounting Kit without Crankarm Kit (quantity 1)
M9203-115 Universal Mounting Kit with Crankarm Kit (quantity 1)
M9203-150 Crankarm Kit (quantity 1)
M9203-250 Remote Mounting Kit with Crankarm Kit and Damper Linkage for D1300 Dampers (quantity 1)
M9203-601 Replacement Standard Coupler Kit (with Retainer) for Mounting M9203 Series Electric Spring Return
Actuators (quantity 1)
M9203-602 Replacement Retainer for M9203 Series Electric Spring Return Actuators (quantity 5)
M9203-603 Adjustable Stop Kit for M9203 Series Electric Spring Return Actuators (quantity 1)
Mounting
The M9203-Bxx-2(Z) Series On/Off Electric Spring Return Actuators can be easily installed on dampers with round
shafts from 1/4 to 1/2 in. (6 to 12 mm) or square shafts from 1/4 to 5/16 in. (6 to 8 mm) using the standard shaft
coupler included with the actuator. If the damper shaft extends less than 3.31 in. (84 mm), see the Removable
Coupler section for further instructions. If the damper shaft extends less than 0.79 in. (20 mm), install a shaft
extension recommended by the damper manufacturer.
