Special Tools Needed

• 10 mm wrench/socket
• drill with Phillips bit, driver size 1
Dimensions
6-3/8
(162)
4-55/64
(123.6)
1-1/8
(28.7)
Figure 1: M9203-Bxx-2 Series On/Off Electric Spring Return Actuator Dimensions, in. (mm)
M9203-Bxx-2(Z) Series On/Off Electric Spring Return Actuators Installation Guide
3-15/16
(82)
25/32
10 30 10 30
50 50
70 70
90 90
4-15/64
(107.5)
5/16 (8) Slot Length
1/4 (6.5) Slot Width
47/64
(18.7)
1-35/64
(39.2)
45/64
(18)
(20)
2
2-1/4
(57.5)
15/64
(6)
