Ambient Conditions - Johnson Controls M9203-B Series Installation Manual

M9203-Bxx-2(Z) Series On/Off Electric Spring Return Actuators (Part 2 of 2 )
Rotation Time Power On
for 90 Degrees of (Running)
Travel -Bxx-2 Models
Power On
(Running)
-BUx-2Z Models
Power Off
(Spring Returning)
Life Cycles
Audible Noise Power On
Rating (Running)
-Bxx-2 Models
Power On
(Running)
-BUx-2Z Models
Power On
(Holding)
Power Off
(Spring Returning)
Electrical Actuator
Connections (All Models)
Auxiliary Switch
(-xxB Models)
Conduit Connections
Mechanical Round Shafts
Connections
Square Shafts
Enclosure Rating
Ambient Standard Operating
Conditions
Storage
Dimensions
Compliance United States
Canada
Europe
Australia and New
Zealand
Shipping Weight
The performance specifications are nominal and conform to acceptable industry standards. For application at conditions beyond these
specifications, consult the local Johnson Controls office. Johnson Controls, shall not be liable for damages resulting from misapplication or
misuse of its products.
M9203-Bxx-2(Z) Series On/Off Electric Spring Return Actuators Installation Guide
53 to 71 Seconds for 0 to 27 lb·in. (3 N·m) Load, at Room Temperature
60 Seconds Nominal at Full Rated Load (0.25 rpm)
24 to 28 Seconds for 0 to 27 lb·in. (3 N·m) Load, at Room Temperature
27 Seconds Nominal at Full Rated Load (0.5 rpm)
19 to 23 Seconds for 0 to 27 lb·in. (3 N·m) Load, at Room Temperature
22 Seconds Nominal at Full Rated Load
28 Seconds Maximum with 27 lb·in. (3 N·m) Load at -22°F (-30°C)
60,000 Full-Stroke Cycles with 27 lb·in. (3 N·m) Load
<36 dBA at 27 lb·in. (3 N·m) Load, at a Distance of 39-13/32 in. (1 m)
<45 dBA at 27 lb·in. (3 N·m) Load, at a Distance of 39-13/32 in. (1 m)
<20 dBA at a Distance of 39-13/32 in. (1 m)
<51 dBA at 27 lb·in. (3 N·m) Load, at a Distance of 39-13/32 in. (1 m)
48 in. (1.2 m) UL 758 Type AWM Halogen-Free Cable with 18 AWG
(0.85 mm²) Conductors and 0.25 in. (6 mm) Ferrule Ends
48 in. (1.2 m) UL 758 Type AWM Halogen-Free Cable with 18 AWG
(0.85 mm²) Conductors and 0.25 in. (6 mm) Ferrule Ends
Integral 1/2 in. (13 mm) Threaded Conduit Connector(s)
Range of Sizes: 1/4 to 1/2 in. (6 to 12 mm)
Range of Sizes: 1/4 to 5/16 in. (6 to 8 mm)
NEMA 2 (IP54) for All Mounting Orientations
-22 to 140°F (-30 to 60°C); 90% RH Maximum, Noncondensing
-40 to 185°F (-40 to 85°C); 95% RH Maximum, Noncondensing
6.38 x 3.23 x 2.26 in. (162 x 82 x 57.5 mm)
UL Listed, CCN XAPX, File E27734; to UL 60730-1A: 2003-08, Ed. 3.1,
Automatic Electrical Controls for Household and Similar Use; and
UL 60730-2-14: 2002-02, Ed. 1, Part 2, Particular Requirements for Electric
Actuators. (Models: All)
Plenum Rated (UL 2043). Suitable for use in other environmental air space
(plenums) in accordance with Section 300.22 (C) of the National Electric
Code
UL Listed, CCN XAPX7, File E27734; to UL 60730-1:02-CAN/CSA:
July 2002, 3rd Ed., Automatic Electrical Controls for Household and Similar
Use; and CSA C22.2 No. 24-93 Temperature Indicating and Regulating
Equipment (Models: All).
CE Mark – Johnson Controls, declares that this product is in compliance with
the essential requirements and other relevant provisions of the
EMC Directive and Low Voltage Directive.
RCM Mark, Australia/NZ Emissions Compliant (Models: All)
-BxA Models: 2.0 lb (0.9 kg)
-BxB Models: 2.4 lb (1.1 kg)
11
