The Matrix network is designed to conveniently accommodate a large number of accessory devices. As more products utilizing CAT5
connectivity are integrated into the vehicle, routing of the cables can be accomplished in 'daisy chain' fashion, if desired. Serial lightbars
utilizing CAT5 will always be the last device in either the PRI-1 or SEC-2 chain. Further instructions, features, and control options are
detailed in the installation manual of the customer selected central node.
The following table indicates the default flash patterns of the serial lightbar. These patterns are activated by other Matrix compatible
products, connected to the lightbar. These can easily be reconfigured as desired, in the Matrix Configurator. See Matrix Configuration Quick
Start Manual for details.
Flash Patterns
Default
Arrowstik Right
Right Scene
Left Scene
Takedown/Alley Flash
Arrowstik Left
Dim
Cruise
Level 3
Level 2
Level 1
Takedown
Front Cut
Arrowstik Flash
Description
Building Fast
Steady
Steady
Single Flash 150 - Alternating
Building Fast
30%
Dim, Full Bar
Pursuit - Alternating
Triple Flash 115
Sweep
Steady
Quad Flash 115
