Power Supply
Power adapter & Battery board
2, Battery board – J1
JAB2 supports battery power which improves the
portability.
J1
MPPT charging circuit is equipped in JAB2. So, you can
use AA-JA11113 to power JAB2.
2
When you want to charge batteries with AA-JA11113,
connect the power supply and battery board together
with JAB2. The voltage of the power supply is suggested
to be larger than 15V and the current is larger than 1A.
