- Page 1 JAB5 Connection Guide BY SURE ELECTRONICS CO., LTD.
- Page 2 JAB5 features low power consumption and high efficiency, suitable for home audio, DIY audio, Bluetooth speakers and digital crossover applications. JAB5 supports Bluetooth input, line input and I2S input. Signal would be mixed and delivered to speaker output. Portable...
- Page 3 What is JAB5? JAB5 supports 4.0 mode (4 x 100W), 2.1 mode (2 x 100W + 1 x 200W) and 2.0 mode (2 x 200W). The switch between the three modes are achieved by automatic cables identification, without any need of other operations. Furthermore, JAB5 supports cascading with another JAB5 to get 8 x 100W or other audio systems through the I2S output port.
-
Page 4: Block Diagram
Block Diagram Copyright© 2020 Sure Electronics Co., Ltd. -
Page 5: Connection Diagram
Power Supply DC10V-39V power supply Speaker Output Input Audio Input Output JAB5 supports PBTL mode, each 2 Bluetooth 5.0 module channels can be configured as one I2S Input channel with double power. The switch of the output mode is based... - Page 6 Connection Diagram Control POT4 Programming POT3 Control POT2 Control Synchronization Port Synchronization Port POT1 Standby Control Bluetooth Pairing Cancellation Potentiometers SW1: Switch between Master mode and Slave mode.
-
Page 7: Power Supply
The terminal interface used for power supply is Molex MiniFit-2x2Pos-4.2mm. A power supply cable is the basic cable, which comes with JAB5 in the package. Copyright© 2020 Sure Electronics Co., Ltd. -
Page 8: Audio Input
Audio Input BT & 3.5mm AUX IN & I2S input JAB5 supports three input methods: BT 5.0, I2S input and analog line input, which makes it suitable for various audio projects. All the signal would be mixed. AUX IN I2S Input Input Copyright©... - Page 9 HD, apt-X LL, SBC & AAC . There is a built-in Bluetooth antenna on the board for stable connection. So you can directly use JAB5 for audio playback. Copyright© 2020 Sure Electronics Co., Ltd.
- Page 10 HD, apt-X LL, SBC & AAC . An external Bluetooth antenna port is also provided, which ensures the stability even if JAB5 is installed in a cabinet. Copyright© 2020 Sure Electronics Co., Ltd.
- Page 11 You can find the PH-6Pos cable in the Functional Cables Kit. Input 4, Analog Line Input – J5 JAB5 supports analog input and J5 is used for 3.5mm AUX IN. You can find the 3.5mm AUX IN cable in the Functional Cables Kit.
-
Page 12: Audio Output
Speaker output 5, Stereo speaker output – J13, J14 JAB5 works as 4 x 100W. It also supports configured as 2.0 / 0.2 mode (2 x 200W) or 2.1 mode (2 x 100W + 1 x 200W). The switch is achieved by automatic cables identification. - Page 13 Audio Output Speaker output 4.0 Mode 2.1 Mode 2.0 / 0.2 Mode 4 x 100W 2 x 100W + 1 x 200W 2 x 200W Output Mode & Settings Copyright© 2020 Sure Electronics Co., Ltd.
- Page 14 I2S amplifier board. You can connect JAB5 with another JAB5 to build an 8 x 100W audio system. A switch is provided on JAB5 to set as master mode or slave mode. Copyright© 2020 Sure Electronics Co., Ltd.
- Page 15 Audio Output I2S output 5, I2S output – J7 If JAB5 receives I2S from other device, it must be set as slave mode through the SW1 provided on board. Slave Mode If JAB5 provides I2S signal to other device, it must be set as master mode through the SW1 provided on board.
-
Page 16: Led Indicator
When Bluetooth is searching, the LED will BLINK. 8, Signal Detection LED indicator – J12 Signal level sensor system is employed in JAB5 for lower power consumption. Therefore, JAB5 provides an indicator for signal detection. When there is signal detected, the LED will be ON;... - Page 17 Control Programming 9, Programming – J3 Based on integrated ADAU1701 DSP, you can connect JAB5 with ICP3 or higher version(s) to get PC UI control, SigmaStudio Control or Bluetooth LE control. You can adjust parameters of the audio system to customize your audio by any of the three methods.
- Page 18 Please do not use J10 when JAB5 is used separately. You can find the PH-3Pos cable in the Function cables kit.
- Page 19 Standby Control 11, Standby Control – J11 J11 port is provided for easy control of the audio systems. Short circuit J11, JAB5 will enter into standby mode. Release the short circuit, JAB5 will work normally. You can find the PH-2Pos cable in the Functional cables kit.
- Page 20 When Bluetooth is paired, short circuit J4 to cancel pairing. After cancellation, please release short circuit. You can find the Bluetooth pairing cancellation cable with a button in the Functional cables kit. When Bluetooth is paired, press the button for cancellation. Copyright© 2020 Sure Electronics Co., Ltd.
- Page 21 Control Potentiometers 13, External Potentiometers Four ports for external potentiometers are provided on JAB5 for POT4 hardware control of the whole system. You can find the cables POT3 POT2 along with potentiometers in the Functional cables kit. POT1 POT4: Gain of power stage channel 1...
- Page 22 1. The channel 1 speaker output (J14) of JAB5 is defined as CH1; channel 2 speaker output (J13) is defined as CH2. 2. POT1 and POT2 are used to adjust CH2 output, POT3 and POT4 are used to adjust CH1 output. When JAB5 works as 2.1 mode, you can configure any channel as 0.1.
- Page 23 Control Hardware Control Function Range of Frequency High-pass Filter (4.0 / 2.0 Mode) 20Hz- 2kHz High-pass Filter (2.0 Mode) 250Hz- 2kHz 60HZ-120Hz (High-pass) Band-pass Filter 200Hz-400Hz (Low-pass) Copyright© 2020 Sure Electronics Co., Ltd.
- Page 24 Sure Electronics Co., Ltd. Professional Audio Solution Provider 3F, Building F6, No. 9, Weidi Road, Xianlin, Qixia Dist., Nanjing, China Tel: +86-025-85260046 Web: store.sure-electronics.com Email: info@sure-electronics.com Skype: sureelectronics WeChat Website YouTube Online Shop Copyright© 2020 Sure Electronics Co., Ltd.
