  • Page 1 BY SURE ELECTRONICS CO., LTD.
  • Page 2 What is JAB3+? JAB3+ is audio amplifier board integrated with high performance Bluetooth 5.0 (Supporting various audio formats as apt-X, apt-X HD, apt-X LL, SBC & AAC) and ADAU1701 DSP, supporting battery power, suitable for portable Bluetooth speakers, hotel audio, home audio, DIY applications and digital crossover applications.
  • Page 3 What is JAB3+? Four connectors for external potentiometers are pre-mounted on the board for easy control of audio system in case of you want to integrate JAB3+ in a cabinet. In addition to hardware control, with the connection of WONDOM ICP3 or higher versions, JAB3+ supports programming with SigmaStudio or remote control through APP or PC UI.
  • Page 4 Block Diagram of JAB3+...

  • Page 5: Connection Diagram

    Connection Diagram Power Supply Control 12-26V power adapter BT Pairing Cancellation WONDOM BCPB series Programming Standby and mute POT4 Audio Input POT3 Potentiometers Bluetooth 5.0 module POT2 POT1 LED Indicator 3.5mm AUX IN Bluetooth indicator Audio Output Signal detection Speaker Output indicator Line output for cascading Extension Function...

  • Page 6: Power Supply

    Power Supply 1, Power supply – J8 Suggested power supply should be 19V 2.1A. You can also use any power supply whose output voltage is within DC12-26V and current is higher than 1A. Please note power supply out of the recommended range may cause damage to the amplifier board.
  • Page 7 Power Supply 2, Battery board – J6 Besides power supply, JAB3+ supports battery power which greatly improves the portability. There is no charging circuit equipped on JAB3+. If you want to power JAB3+ with battery power, it is suggested to use WONDOM BCPB series, which are integrated with charging circuit.

  • Page 8: Audio Input

    Audio Input JAB3+ supports both Bluetooth input and 3.5mm line input. Signals from the two input methods will be mixed before being transmitted to the amplification circuit. AUX IN JAB3+...
  • Page 9 Audio Input 3, Bluetooth input JAB3+ is integrated with Bluetooth 5.0 module, supporting various audio formats as apt-X, aptX HD, apt-X LL, SBC & AAC . There is a built-in Bluetooth antenna on the board for stable connection. So you can directly use JAB3+ for audio playback.
  • Page 10 Audio Input 3, Bluetooth input JAB3+ is integrated with Bluetooth 5.0 module, supporting various audio formats as apt-X, aptX HD, apt-X LL, SBC & AAC . An external Bluetooth antenna port is also provided, which ensures the stability even if JAB3+ is installed in a cabinet.
  • Page 11 Audio Input 4, 3.5mm AUX IN – J9 JAB3+ supports line input and J9 is used for 3.5mm AUX IN. You can get the 3.5mm AUX-IN cable in the Functional cables kit for JAB3+ (AA-JA11117).

  • Page 12: Audio Output

    Audio Output 5, Speaker Output – J10 JAB3+ includes four models, 2 x 50W, 2 x 30W, 1 x 100W and 1 x 60W. 2 x 30W and 1 x 60W do not have the heatsink and their amplifier chip is different from that of the 2 x 50W and 1 x 100W.
  • Page 13 Audio Output 6, Line output – J7 JAB3+ provides a line output signal to connect with other WONDOM standard amplifier boards to build audio 2.1/4.0 system. The output mode of this line output (stereo or mono) can be configured by customers through SigmaStudio or APP according to the connected board.
  • Page 14 Control 7, Bluetooth pairing cancellation – J3 When Bluetooth is paired, short circuit J3 to cancel pairing. After cancellation, please release short circuit. You can find the Bluetooth pairing cancellation cable with a button in the Functional cables kit for JAB3+ (AA-JA11117). When Bluetooth is paired, press the button for cancellation.
  • Page 15 Control 8, Programming – J5 Based on integrated ADAU1701 DSP, you can connect JAB3+ with ICP3 or higher version(s) to get PC UI control, SigmaStudio Control or Bluetooth LE control. You can adjust parameters of the audio system to customize your audio by any of the three methods.
  • Page 16 Control 9, Standby & Mute control – J12 The pin definition of J12 is as follows: Definition STBY MUTE Short circuit “STBY” and “GND” to enter into standby mode. Release for normal playback. “Mute” is for control synchronization with the cascading amplifier board so that their control logic can be consistent.
  • Page 17 Control 9, Potentiometers Control Four ports for external potentiometers are provided on JAB3+ for hardware control of the whole system. You can find the cables POT4 along with potentiometers in the Functional cables kit for JAB3+ POT3 (AA-JA11117). POT2 POT1 POT4: Overall Volume POT3: High-pass filter or Band-pass filter of power stage channel POT2: High-pass filter of signal output channel...
  • Page 18 Control Hardware Control Function Range of Frequency High-pass Filter (Stereo Mode) 20Hz- 2kHz High-pass Filter (Mono Mode) 250Hz- 2kHz 60HZ-120Hz (High-pass) Band-pass Filter 200Hz-400Hz (Low-pass)
  • Page 19 External LED Indicator 11, External Bluetooth LED indicator – J1 When Bluetooth is paired, the LED will be ON; When Bluetooth is searching, the LED will BLINK. 12, External Signal Detection LED indicator – J11 Signal level sensor system is employed in JAB3+ for lower power consumption.

  • Page 20: Extension Function

    Extension Function 13, Extension Port– J4 To provide customers with more playability and expandability, we extended several pins of ADAU1701 as J4, through which port, you can develop more functions with JAB3+, such as I2S input and output.
  • Page 21 Extension Function J4 can be used for I2S input and I2S output. JAB3+ is set as master Mapping of ADAU1701 mode as default when using I2S. Please refer to the below table for Pin of J4 ADAU1701 reference. 1, GND AGND For I2S input: For I2S output:...
