Bradley FREQUENCY FL-1H Installation Manual

FL-1H
FL-1L
Installation
Packing List



IS
T H
E
S ID
U P
215-1511 Rev. D; EN 07-808
© 2007 Bradley Corporation
Page 1 of 8 5/30/07
IMPORTANT!
Read this entire installation manual to ensure proper installation.
When fi nished with the installation, fi le this manual with the owner or
maintenance department. Compliance and conformity to local codes
and ordinances is the responsibility of the installer.
Separate parts from packaging and make sure all parts are accounted
for before discarding any packaging material. If any parts are missing,
do not begin installation until you obtain the missing parts.
Make sure that all water supply lines have been fl ushed and then
completely turned off before beginning installation. Debris in supply
lines can cause valves to malfunction.
Turn OFF electrical power to the electrical outlets, then unplug all
electrical units prior to installation. Electrical power MUST remain off
until installation is completed. After installation is complete, turn on
the water supply fi rst, then turn on the electrical power.
Hardware supplied by installer must be appropriate for wall
construction. Wall anchors used must have a minimum pull-out rating
of 1,000 lbs.
Product warranties may be found under "Product Information" on our
web site at www.bradleycorp.com.
Installation
FL-1H, FL-1L
Frequency® Lavatory System
U.S. Pat. No. Des. 507,634

Table of Contents

Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Supplies Required . . . . . . . . . . . . . . . . . . . . . . . .2
Cleaning and Maintenance for Terreon® . . . . . . .3
Dimensions - Front and Top Views . . . . . . . . . . . . . 3
Dimensions - Side Views . . . . . . . . . . . . . . . . . . . . . 4
Rough-Ins . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-8
P.O. Box 309, Menomonee Falls, WI 53052-0309
Phone: 1-800-BRADLEY
www.bradleycorp.com
Fax: 262-253-4161
