Mounting Ring Data:
EMG Mounting Rings are available for 6, 7, and 8 String Humbucking Pickups.
There are 3 styles available; flat, angled, and radius angle with 3 heights available for each style of ring. In addition, all mounting rings are
adaptable to a 3-screw mounting format allowing the pickup to be adjusted paralell under the strings. Pickup rings are supplied without pickup
mounting holes so you can choose either the traditional 2-screw mount or the 3-screw mount. Alignment bosses are molded into the pickup
ring and by using a 7/64 inch (2.5mm) drill they are easily modified per your choice. If the pickup cavity in your guitar is routed to fit the 3-screw
mount then we recommend its use because it allows paralell adjustment of the pickup to the angle of the strings, and adds pickup mounting
strength. EMG Mounting rings are made to match EMG Pickup housings, but will work fine with most any humbucking pickup. Colors available
are Black, White, and Ivory. Made in the U.S.A.
Mounting Ring Dimensions (top view):
6 STRING
3.50
(88.9)
3.17
(80.5)
2.76
(70.1)
1.780 1.51
(38.3)
(45.2)
3.09
(78.5)
Mounting Ring Dimensions (side view):
FLAT
.125
(3.17)
.200
(5.0)
.350
(8.9)
1.780
1.43
(36.3) (45.2)
ANGLED
2.0
.250
(6.35)
2.0
.347
(8.8)
.437
2.0
(11.1)
7 STRING
3.875
(98.4)
3.55
(90.2)
3.15
(80.0)
1.51
(38.3) (36.3)
3.48
(88.3)
Ring Dimensions (side views):
RADIUS/ ANGLED
.187
(4.75)
.285
(7.24)
.374
(9.5)
1.43
1.780
(45.2)
.200
(5.0)
R 42.5"
.347
(8.8)
R 42.5"
.400
(10.1)
R 42.5"
8 STRING
4.250
(108)
3.930
(99.8)
3.53
(89.6)
1.51
1.43
(38.3)
(36.3)
3.860
(98.0)
2.0
.137
(3.48)
2.0
.285
(7.24)
2.0 .333
(8.45)
