LIQUID SOLID BILLET DOOR HANDLE INSTRUCTION SHEET
Congratulations on your purchase of a high quality PUTCO product. Should you need any application or technical
assistance, feel free to call us at:
P
LEASE READ ALL INSTRUCTIONS BEFORE INSTALLATION AND TO CHECK TO SEE THAT ALL PARTS ARE INCLUDED
The installation of the replacement door handles are for persons with
advanced auto-body skills and it is recommended to have them
professionally installed.
Kit Contents
Item #
Quantity
Reqd.
1
2
2
2
Recommended Tools
Safety Tools
Eye Protection
Special Tools
Pull Handle Removal Tool to remove window
crank
Installation Tools
Flat Head Screw Driver
Philips Screw Driver
Pliers
Needle Nose Pliers
10mm Socket
Ratchet
Ratchet Extensions
Alan Wrenches
A. Pre-installation Preparation
Step 1: Verify kit contents.
Step 2: Remove protective wrapping from inserts and place on
a non-abrasive surface.
Step 3: Remove the door handles from the box.
STOP
B. Remove Door Paneling
Step 1: Use the pull handle removal tool to remove the crank handle on manual windows only. You
need to slide the tool between the crank handle and the black gasket to pop the C-clamp off. The
C-clamp is shown in figure B-1. If you have power windows you will need to disconnect the wires.
Step 2
Remove the two Philips head screws from the inside armrest. (Fig. B-2)
:
1988-1998 CHEVY/GMC (2 & 4 DOOR) #90012/#90013
1-800-247-3974 Monday
Contact your PUTCO dealer for other quality accessories.
PUTCO Inc. - 216 West First Street - Story City, Iowa 50248
Description
Door Handles w/keyholes
Door Handles w/o keyholes
-Friday 8:00 a.m. - 5:00 p.m. (Central Standard Time)
.
Fig. B-1
Fig. B-2
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for PUTCO 90012
Summary of Contents for PUTCO 90012
- Page 1 1988-1998 CHEVY/GMC (2 & 4 DOOR) #90012/#90013 LIQUID SOLID BILLET DOOR HANDLE INSTRUCTION SHEET Congratulations on your purchase of a high quality PUTCO product. Should you need any application or technical 1-800-247-3974 Monday assistance, feel free to call us at: -Friday 8:00 a.m.
- Page 2 1988-1998 CHEVY/GMC (2 & 4 DOOR) #90012/#90013 LIQUID SOLID BILLET DOOR HANDLE INSTRUCTION SHEET Step 3 Remove plastic cover from the door handle and door lock area shown in figure B-3. Use a flat head screw driver to pop the cover off there is six tabs that hold it in place. If you have power locks there will be wires you need to disconnect.
- Page 3 1988-1998 CHEVY/GMC (2 & 4 DOOR) #90012/#90013 LIQUID SOLID BILLET DOOR HANDLE INSTRUCTION SHEET D. Remove Factory Door Lock (Only for handles with Key Holes) Step 1 Remove the factory door lock from the factory door handle. Step 2 There is three parts to the lock. First you have the top piece which acts as a lock.
- Page 4 Black products have a 90-day warranty on the painted surface. Any defects resulting from faulty material or workmanship will be warranted by Putco and repaired or replaced at our discretion. Putco assumes no extra labor costs. Damages caused by freight carriers, improper installation, misuse, collision, or neglect will not be warranted by Putco.
