Troubleshooting

Display Condition
Check Sensor?
Too much error
CHECK SENSOR
Reset to Factory
Calibration
Open Collector is always
activated
Value must be
400 or less

Ordering Information

Mfr. Part No. Code
3-8350-1 159 000 192
3-8350-1P 159 000 193
3-8350-2 159 000 194
3-8350-2P 159 000 195
3-8350-3 159 000 196
3-8350-3P 159 000 197
Accessories
Mfr. Part No. Code
3-8050 159 000 184
3-8052 159 000 188
3-8052-1 159 000 755
3-8050.395 159 000 186
3-8050.396 159 000 617
3-0000.596 159 000 641
3-5000.598 198 840 225
3-9000.392 159 000 368
3-9000.392-1 159 000 839
3-9000.392-2 159 000 841
3-9900.396 159 001 701
Georg Fischer Signet LLC, 3401 Aerojet Avenue, El Monte, CA 91731-2882 U.S.A. • Tel. (626) 571-2770 • Fax (626) 573-2057
For Worldwide Sales and Service, visit our website: www.gfsignet.com • Or call (in the U.S.): (800) 854-4090
For the most up-to-date information, please refer to our website at www.gfsignet.com
3-8350.090-1 Rev. H 01/12 English
Possible Causes
• Sensor not wired properly.
• Sensor connected to 8350 while power
is on.
• Defective sensor.
The value entered in Set Temperature
fi eld is greater than 20 °C (36 °F)
deviation from sensor input. (The 8350
allows a maximum of 20 °C offset.).
Value in SET TEMPERATURE fi eld
is -999.
• Hysteresis value too large.
• Defective transmitter.
Value entered in Output PlsRate fi eld is
greater than 400.
Description
Temperature transmitter Field mount
Temperature transmitter Panel mount
Temperature transmitter Field mount with relays
Temperature transmitter Panel mount with relays
Temperature transmitter Field mount with dual input/output
Temperature transmitter Panel mount with dual input/output
Description
Universal mounting kit
3/4" Integral mounting kit
3/4" NPT mount junction box
Splashproof rear cover
RC Filter kit (for relay use)
Heavy duty wall mount bracket
Surface Mount Bracket
Liquid tight connector kit for rear cover (includes 3 connectors)
Liquid tight connector kit, NPT (1 piece)
Liquid tight connector kit, PG13.5 (1 piece)
Angle Adjustment Adapter Kit
© Georg Fischer Signet LLC 2012
Suggested Solutions
• Correct sensor wiring.
• Recycle power with all sensors connected.
• Replace defective sensor.
• Confi rm calibration values.
• Replace defective sensor.
Entering "-999" in this fi eld will remove all user
calibration input and restore the factory values.
• Change the hysteresis value
• Replace transmitter
Select a maximum pulse rate of 400 pulses per
minute or less.
