Signet 8350-1 Manual page 7

Options Menu
Display
(Factory settings shown)
Contrast:
3
Averaging
Off
Output Active
Low
Loop Adjust
4.00 mA
Loop Adjust
20.00 mA
Test Loop:
Test Output:
8350-1 Temperature Transmitter
Adjust the LCD contrast for best viewing. A setting of 1 is lowest contrast, 5 is highest. Select
> lower contrast if the display is in warmer ambient surroundings.
OFF provides the quickest output response to changes in temperature. Longer averaging
> period produces more stable display and output response.
Active HIGH: This setting is used to turn a device (pump, valve) ON at the setpoint.
Active LOW: This setting is used to turn a device OFF at the setpoint.
>
Adjust the minimum and maximum current output. Use this setting to match the system output
> to any external device. The display value represents the precise current output.
Adjustment limits:
• 3.80 mA < 4.00 mA > 5.00 mA
>
• 19.00 mA < 20.00 mA > 21.00 mA
Press ▲ or ▼ keys to manually order any output current value from 3.6 mA to
21.00 mA to test current loop output.
>
Press ▲ or ▼ keys to manually toggle the state of open collector output.
>
Description
7
