LED Status
TABLE 2-1
Yellow LED
Off
On
Flash
*
Flash in sequence
Off
Off
On (for link up) or
Flash (if I/O activity)
Flash
* Flash sequence is yellow LED > green LED > amber LED, then back to yellow LED.

Testing the Installation

This section contains the following topics:
"To Verify Proper Installation (SPARC Systems)" on page 16
■
"To Verify Attached Storage (SPARC Systems)" on page 19
■

▼ To Verify Proper Installation (SPARC Systems)

1. Use the show-devs command at the ok prompt to list the installed devices.
The HBA can be identified in the output by looking for the SUNW,qlc@n and
SUNW,qlc@n,1 node names, where n is usually a single-digit number from 0 to 9.
In this example, there is a dual port HBA (SG-SPCIE2FC-QF8-Z) installed.
{0} ok show-devs
/ebus@c0
/pci-performance-counters@0
/pci@0
/niu@80
16 Sun StorageTek 8 Gb FC PCI-Express HBA Installation Guide • September 2009
Green LED
Off
On
Flash
*
Flash in sequence
Off
On (for link up) or
Flash (if I/O activity)
Off
Off
Amber LED
Off
On
Flash
*
Flash in sequence
On (for link up) or
Flash (if I/O activity)
Off
Off
Flash
State
Power off
Power on (before firmware
initialization)
Power on (after firmware initialization)
Firmware fault
2 Gbps link UP/ACT
4 Gbps link UP/ACT
8 Gbps link UP/ACT
Beacon
