RL SERIES INSTALLATION MANUAL

Vertical Dimensions

7-10 Tons
TOP DISCHARGE
CONTROL BOX
AND WATER
LEFT RETURN
CP
2' PRIMARY
SERVICE ACCESS
FOR LEFT RETURN
AP
CMP
2' SECONDARY
SERVICE ACCESS
2.9 in
[7.4 cm]
34.1 in
[86.6 cm]
21.6 in
[54.9 cm]
AIR COILS
36.3 in
[92.2 cm]
34.4 in
[87.4 cm]
7.2 in
[18.3 cm]
DRAIN CONNECTION
12.5 in [31.8 cm]
2.6 in [6.6 cm]
WATER OUT
WATER IN
CONTROL BOX
RIGHT RETURN
CP
2' PRIMARY
SERVICE ACCESS
FOR RIGHT RETURN
61.3 in [155.8 cm]
58.1 in [147.6 cm]
16.1 in
[40.9 cm]
18.1 in 1.42 in
[46.0 cm] [3.6 cm]
1 in [2.5 cm]
56 in
[142.2 cm]
2 in [5.1 cm]
LEFT RETURN
2.2 in
[5.6 cm]
ELECTRICAL
CONNECTIONS
15.6 in
[39.6 cm]
10.1 in [25.7 cm]
4.0 in [10.2 cm]
2.0 in
[5.1 cm] 2.2 in [5.6 cm]
Legend
AP = Alternate Service Panel
BP = Blower Service Panel
CP = Control Access Panel
CMP = Compressor Service Panel
CONTROL BOX AND WATER
LEFT RETURN
2' PRIMARY
SERVICE ACCESS
FOR LEFT RETURN
2' SECONDARY
SERVICE ACCESS
2.9 in
[7.4 cm]
TOP VIEW
Left or Right Return
34.1 in
[86.6 cm]
SIDE VIEW
Left or Right Return
56 in
[142.2 cm]
2 in [5.1 cm]
RIGHT RETURN
TOP OR SIDE DISCHARGE
ELECTRICAL
CONNECTIONS
15.6 in
[39.6 cm]
10.1 in [25.7 cm]
4.0 in [10.2 cm]
2.2 in [5.6 cm]
6
SIDE DISCHARGE
CP
AP
CMP
61.3 in [155.7 cm]
58.1 in [147.6 cm]
TOP PANEL
22.6 in
16.1 in
COVER
[57.4 cm] [40.9 cm]
1.8 in [4.6 cm]
2.2 in
[5.6 cm]
7.2 in
[18.3 cm]
12.5 in [31.8 cm]
WATER OUT
2.0 in
[5.1 cm]
WATER IN
CONTROL BOX
RIGHT RETURN
CP
2' PRIMARY
SERVICE ACCESS
FOR RIGHT RETURN
18.1 in [46 cm]
AIR COILS
36.3 in
[92.2 cm]
34.4 in
[87.4 cm]
DRAIN CONNECTION
2.6 in [6.6 cm]
REV 2/11/08
