7.3. Appendix C : Example system schematic and wiring diagram

11 x 270W 60 cell panels in
series – 418 Voc
418V and 304V DC PV Distribution
Both Communications cables shown in diagram,
USE ONLY ONE of either VE.Can or VE.Direct
connections
Page 29
Isolated SmartSolar MPPT RS
8 x 270W 60 cell panels in
series – 304 Voc
ACout1 Acin ACout2
L PE N L PE N L PE N
48V Battery*
* minimum float voltage of 52.3V (PV voltage
AC Input Supply - Either
Grid Generator
Critical AC Loads
MultiPlus ACin
ACout
ACin ACout1
ACin ACOut1
AC
Distribution
÷ 8)
Appendix
