- Page 1 I N S T R U C T I O N F O R U S E VELA Samba 400/410/420/500/510/520/530 VARIANT: Manual no. 105563 VELA Samba 530 VELA Samba 510 VELA Samba 520 VELA Samba 410 VELA Samba 400 VELA Samba 500...
-
Page 2: Table Of Contents
1.9.7. Adjustment of seat tilt (Samba 400 & 530) 1.9.8. Adjustment of back height (Samba 520) 1.9.9. Adjustment of back tilt (Samba 520) 1.9.10. Adjustment of seat height, VELA Samba 410 1.9.11. Adjustment of armrest, height* 1.9.12. Adjustment of armrest, width* 1.9.13. -
Page 3: Introduction
1.0. INTRODUCTION DEAR CUSTOMER Congratulations on your new VELA/VELA Medical chair! We are sure this chair will give you daily pleasure. This user manual provides useful information on adjusting, operating and maintaining your chair. Important Please read this user manual carefully and keep it safe for when you need to refer to it. -
Page 4: Warnings
1.1. WARNINGS In case of an allergic reaction, stop using the chair and consult a doctor Only use original spare parts from VELA/VELA Medical Do not make any changes to the accessories that come with the chair Only use the chair for the intended purpose Only adjust the seat angle while the user’s feet are on the floor... -
Page 5: Troubleshooting
Contact your VELA/VELA Medical supplier The chair rolls badly Wheels are blocked. Clean the wheels for wire residue and the like. If the above does not solve your problem, you should contact your VELA/ VELA Medical supplier. -
Page 6: Labels Used On The Chair
IN GENERAL 1.3. LABELS USED ON THE CHAIR Risk of shear and squeeze: Warning Keep hands and fingers away from moving parts Icon Read ”Instruction For Use” before use Icon Part used: Type B cf. IEC60601-1 covering the following areas of the chair: Labels 60 x 22.5 mm <Model name>... -
Page 7: Safety
All variants of this chair are tested and approved for a maximum load :: Misuse of 125 kg. Warning: VELA Samba 410 is tested :: Normal wear and tear and approved for a maximum user :: Wrong use weight of 95 kg. -
Page 8: Maintenance
The life expectancy of the chair is check the wheels and remove any five years for regular and proper residual threads, etc. use as long as VELA/VELA Medical, your VELA/VELA Medical supplier or a trained professional perform an 1.7.2. FRAME... -
Page 9: User Manual
1.9. USER MANUAL Replacement of the gas spring may only be performed by the service support team from your dealer or a skilled technical person. 1.9.1. ATTACHING THE BACKREST The lever for backrest adjustment (1) must be in open position. Press the locking pin spring (2) and push the backrest arm through the hole. -
Page 10: Adjustment Of Seat Height (Samba 400 & 530)
1.9.5. ADJUSTMENT OF SEAT HEIGHT (SAMBA 400 & 530) Adjust the seat height by pushing the lever placed at your VELA SAMBA left hand. 400 & 1.9.6. ADJUSTMENT OF SEAT TILT (SAMBA 520) Adjust the seat tilt by pushing the middle lever placed at your VELA right hand. -
Page 11: Adjustment Of Back Tilt (Samba 520)
Adjust the back tilt by pushing the rear lever placed at your VELA SAMBA right hand. 420 & 1.9.10. ADJUSTMENT OF SEAT HEIGHT, VELA SAMBA 410 Adjust the seat tilt by pushing the lever placed at your VELA right hand. SAMBA 1.9.11. -
Page 12: Footrest Ring
* Depending on model vela.eu VELA :: Gøteborgvej 8-12 :: 9200 Aalborg SV :: Denmark :: +45 96 34 76 00 :: mail@vela.dk VELA Medical :: Gøteborgvej 8-12 :: 9200 Aalborg SV :: Denmark :: +45 96 34 76 00 :: mail@vela-medical.com vela-medical.com...
