OSD Menu_Color

WB mode
WHITE BAL. AUTO
COLOR GAIN 10
RETURN
Auto Compensates for color temperature change between 2400K° and 12000K° .
Compensates for color temperature change under 2400K° and over 12000K°.
AUTOext
Automatically set the white balance based on the current lighting conditions.
Preset
Manually set the white balance by changing red gain and blue gain.
Manual
C-Temp: Select the color temperature for the white balance setup.
Red gain: 0 ~ 20. Adjusts the amount of red in the image.
Blue gain: 0 ~ 20. Adjust the amount of blue in the image.
Color gain Set the color gain from 0~20.
COLOR
RGB
If enabled, the red and blue gain settings will be set automatically
according to the C-TEMP selected.
21
WHITE BAL.
C-TEMP 5000K
R-GAIN 10
B-GAIN 10
RETURN
