Digital Watchdog STAR-LIGHT PLUS DWC-D3853WTIRW User Manual page 13

Installation - Instructions
Using the mounting template or your camera,
1
mark and drill the necessary holes in the
mounting surface.
Pull all necessary wires through and make the
2
proper connections. See pages 14.
Use the two (2) mounting screws to install the
3
camera onto the mounting surface. See page
15 for tilting and pan adjustment options.
When the installation is completed, place the
4
camera's dome over the camera's body by
clicking the dome into place.
Detach the protective cover from the dome to
5
complete the installation.
13
