PAN/TILT ZOOM CONTROLLER
Rear Panel Controls
Rear Panel Controls
~
AC INPUT
230V 50Hz, 10W
1
1. AC INPUT
AC input cord terminal.
2. CONTROL SIGNAL OUTPUT TERMINAL
The signal controlled from front is transmitted to pan/tilt driver through these terminals.
3. EXT SELECT OUTPUT TERMINAL
It is for external channel selection connection with VSW-1208 or VQD-1204/VQD-1305. This
allows direct or binary output.
4. LENS VOLTAGE CONTROL SWITCH
External ±6V/±9V voltage selection for various zoom speed change.
4
VRC-1104T
CAUTION;
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER.
MODEL NO. VRC-1104T
NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
PAN/TILT ZOOM CONTROLLER
AVIS;
RISQUE DE CHOC ELECTRIQUE NE PAS OUVRIR.
EXT
LENS
CONTROL
SELECT OUT
4
SELECTOR
6V
9V
3
4
S N
www.inter-m.com
CHANNEL
3
2
2
1
MADE IN KOREA
