Front Panel Controls

Front Panel Controls
2
CH 1
TELE
1. POWER SWITCH
Power on/off switch.
2. CHANNEL SELECT SWITCH
Remote pan/tilt/zoom control among four channels.
3. CONTROL LEVER
Pan/tilt driver control by lever.
4. AUTO PAN SWITCH
Automatic pan/tilt control switch.
5. QUAD SWITCH
Quad screen display linkage with VQD-1204/VQD-1305.
VRC-1104T
PAN/TILT ZOOM CONTROLLER
CHANNEL
QUAD
CH 2 CH 3 CH 4
LENS
ZOOM FOCUS
WIDE FAR NEAR
PAN/TILT ZOOM CONTROLLER
5 3
PAN/TILT
UP
LEFT
AUTO PAN
DOWN
4
1
POWER
ON
OFF
RIGHT
3
VRC-1104T
