III.STRUCTURE AND PERFORMANCE
SPECIFICATION
Overall Dimensions
Seat Height
Seat Width
Seat Depth
Arm Height
Seatback Height
Ba�ery Weight
Wheelchair Weight
Maximum Speed
Braking Distance(on a level surface)
Minimum Turning Radius
水平路面制动
Weight Capacity
Theore�cal Travel Range
Sta�c Stability
Dynamic Stability
Slope Performance
Climing Ability
Motor Type
Lithium Ba�ery Type
Max. Output Current of Controller
Max. Output Current of Charger
Front Wheel
Rear Wheel
7
900mmX600mmX880mm
500mm
400mm
410mm
210mm
420mm
1.4kg
19.8kg without ba�ery
4.5km/h
≤1000mm
900mm
100kg
10km
≥6°
≥3°
≥6°
≥3°
24V/200W*2
24V6.6AH*2
24V10AH*2
35A
2A
Solid �re, Outside size of 178mm
Solid �re, Outside size of 216mm
IV.ASSEMNLY/FOLDING/DEBUG
5.1 Installation
5.1.1 Take out the wheelchair from the packing box and put it on the
ground. Push the backrest and footrest back and forth respectively
by two hands(figure 2). When you hear a click, the locating pins are
inserted into the positioning holes, and in this case, the chair frame
has been completely opened
5.1.2 Fold down the armrest forward(figure 4)
5.1.3 Put the controller on the armrest(figure 5). And then pull down
the tightening spanner on the controller to fasten the controller. (figure 6)
5.1.4 Turn over the wheelchair, press the stopper pins down to release
legs(figure 7) and pull out the anti-tipper until a location pin automatically
lock the anti-tipper(figure 8).
5.1.5 Take out the foam pads from the battery boxes, and then put the
two batteries separately into the right and left boxes(figure 9). Note that
the batteries should be fully inserted in the end(figure 10).
5.1.6 Fold down the footrest forward completely(figure 12).
5.1.7 Switch the motor lock levers on the motors to the "Electric" mode
(figure 11).
5.1.8 Now, your wheelchair has been completely assembled, and can be
used.
figure 4
figure 2
figure 5
8
