In the field "D Add" the address of the endpoint is defined. If "D Len" is '1' it is possible to insert a number from 1 to 255; if "D Len"
is '2' it is possible to insert a number from 1 to 65535; if "D Len" is '6' it is possible to insert an IP and port in this format
"192.168.2.188:47808";
In the field "Poll Time" the frequency of the request is defined (in ms);
In the field "Max Error" the number of consecutive errors that the Master waits before resetting the data for the specific requests is
defined;
In the field "Position" the starting byte of the internal memory array where mapping the data read is defined;
The field "Start Bit" is used for the "Binary Output" BACnet objects. It is possible to select the bit in the byte where saving the data;
In the field "Mnemonic" a description of the data inserted in the row is defined.
