ZSE2/ISE2
Series
Dimensions
Standard Type: ZSE2-
Grommet type: ZSE2-
Pressure setting trimmer
SET
L H
20
2 x ø3.5
13
Mounting hole
Base Mount Type: ZSE2-0R
Grommet type: ZSE2-0R-15
Pressure setting trimmer
Gasket
856
01
T1
01
-15
T1
Indicator light (Red)
Piping port
01: R 1/8
M5 x 0.8 depth 5
T1: NPTF 1/8
Indicator light (Red)
SET
L H
25 2 x M2.5 x 41L
Mounting thread
31
20
18
16
Vacuum supply port ø3.3
Connector type: ZSE2-
Pressure setting trimmer
SET
L H
Indicator light (Red)
20
2 x ø3.5
13 Piping port
Mounting hole M5 x 0.8 depth 5
Connector type: ZSE2-0R-15C
Pressure setting trimmer
Gasket
01
-15C
T1
01: R 1/8
T1: NPTF 1/8
Indicator light (Red)
SET
L H
25 2 x M2.5 x 41L
Mounting thread
31
20
18
16
Vacuum supply port ø3.3
