WOSm water-oil separator
Please read the following instructions carefully before installing separator housing unit into
service. Trouble free and safe operating of the unit can only be guaranteed if
recommendations and conditions stated in this manual are respected.
8102803959- WOSm_v1.02-OmegaAir_eng_ver03092012
Advertisement
Table of Contents
Related Manuals for OMEGA AIR WOSm Series
Summary of Contents for OMEGA AIR WOSm Series
- Page 1 Installation and operating manual WOSm water-oil separator Please read the following instructions carefully before installing separator housing unit into service. Trouble free and safe operating of the unit can only be guaranteed if recommendations and conditions stated in this manual are respected. 8102803959- WOSm_v1.02-OmegaAir_eng_ver03092012...
- Page 2 WOSm - Installation and operating manual Components Part Filter head Inlet connection Outlet connection Wall mounting bracket Filter cap O-rings Filter element...
-
Page 3: Technical Data
WOSm - Installation and operating manual Technical data Cold climate zone Mild climate Hot climate zone Size 15°C 60%RH zone 25°C 60%RH 40°C 100%RH Max oil adsorption[g] WOSm1 1,23/43,05 1,08/37,8 0,62/21,9 Max FAD [Nm /min]/[scfm] 0,57 0,90 1,91 Max condensate flow [l/h] 1520 1340 Max oil adsorption[g]... -
Page 4: Safety Instructions
WOSm - Installation and operating manual Safety instructions The relevant safety at work and accident prevention regulations, plus operating instructions, shall apply for operating the separator. The separator has been constructed in accordance with the generally recognized rules of engineering. Ensure that installation complies with local laws and directives. -
Page 5: Appropriate Use
WOSm - Installation and operating manual Appropriate use WOSm water oil separators are intended for separation of lubricant oil from condensate generated in compressed air systems. This appliance must be used only for the purpose for which it was specifically designed. All other uses are to be considered incorrect. -
Page 6: Installation
WOSm - Installation and operating manual Installation Unpack the device Fill the filter element with clean water! WOSm separator is optimized for mounting on the wall and therefore wall mounting bracket is included. (wall mounting screws are not included) ... -
Page 7: Maintenance
WOSm - Installation and operating manual Maintenance It is rec ommended, that you do a check once per week to evaluate filter element saturation. To test water quality use test set. Instructions are attached in test set. Filter element must be replaced when first of the following parameters appears: ... -
Page 8: Warranty Exclusion
The unit was not operated within the permissible technical parameters. Unauthorised constructional changes were made to the unit or if parts of the unit that may not be opened were dismantled. OMEGA AIR d.o.o. Ljubljana Cesta Dolomitskega odreda 10 SI-1000 Ljubljana, Slovenia Tel.: +386 (0)1 200 68 00...
