L2E Repair Document
Communication Ltd.
Pixi4-7 4G BELL
9015B
Note:
this manual can be modified without prior notice on the characteristics of described
equipment. Please download from Support website for the latest versions.
Rev.
Page
1.0
1/41
9015B Level 2E Repair Document
All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the alcatel Pixi4-7 4G BELL and is the answer not in the manual?

Questions and answers

Related Manuals for TCL alcatel Pixi4-7 4G BELL

Summary of Contents for TCL alcatel Pixi4-7 4G BELL

  • Page 1 L2E Repair Document Communication Ltd. Pixi4-7 4G BELL 9015B Note: this manual can be modified without prior notice on the characteristics of described equipment. Please download from Support website for the latest versions. Rev. Page 1/41 9015B Level 2E Repair Document All rights reserved.
  • Page 2 L2E Repair Document Communication Ltd. 2-Sep-2016 Draft creation Peter Hanson Rev. Date Modification description Prepared By Checked By Approved By Rev. Page 2/41 9015B Level 2E Repair Document All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.

  • Page 3: Table Of Contents

    L2E Repair Document Communication Ltd. Content Level 2E repair process .................... 4 Warranty Check and Visual Inspection ..............4 2.1 Warranty confirmation of L1..................4 2.2 Visual mechanical check ..................5 2.3 Pretest ........................5 Battery ........................6 3.1 Battery information ....................6 3.2 WARNING OF BATTERY disassembling ..............

  • Page 4: Level 2E Repair Process

    L2E Repair Document Communication Ltd. 1 Level 2E repair process Please refer to <L2E repair process> in support (CSS/RSH) website for details. 2 Warranty Check and Visual Inspection 2.1 Warranty confirmation of L1  IMEI sticker check: 1) Power on the handset, enter ”Settings” -> “About tablet” -> “Status” -> “IMEI information” 2) Input *#06# on the dial mode.

  • Page 5: Visual Mechanical Check

    L2E Repair Document Communication Ltd. 2.2 Visual mechanical check Please refer to <Visual mechanical check> in support (CSS/RSH) website for details. 2.3 Pretest Check that the SIM card and SD card are set correctly. Power on the tablet. If the tablet asks to input NCK code, this means it is SIM locked and can only be worked with dedicated SIM card.

  • Page 6: Battery

    L2E Repair Document Communication Ltd. Using For detail instruction of test Smart Diagnosis Tool to proceed with the test: with Smart Diagnosis Tool, please refer to < Smart Diagnosis Manual > in support (CSS/RSH) website. 3 Battery 3.1 Battery information 1) Battery picture 2) Battery feature Model...

  • Page 7: Warning Of Battery Disassembling

    L2E Repair Document Communication Ltd. 3) Battery life The bellowing table shows the nominal battery life respectively in standby and talking mode. These typical values are expressed in normal temperature with battery initially full charged and under good ratio coverage. Battery range depends on the network characteristics, the ambient temperature and particularly on movement.

  • Page 8: Software Download

    L2E Repair Document Communication Ltd. 4 Software download It is authorized to download software for the handset which needs to be updated. This downloading tool is called “Sugar MTK_SP V3.3.5”. Handset Software can be downloaded from TS website via it. Thus internet access is necessary. TS Website: https://css.tclmobile.cn/.

  • Page 9: Disassembly Process

    L2E Repair Document Communication Ltd. 5.3 Disassembly process The steps of disassembly 9015B are as below. Step1: Take off the back cover by using plastic flake. Disconnect the battery with tweezers. Rev. Page 9/41 9015B Level 2E Repair Document All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
  • Page 10 L2E Repair Document Communication Ltd. Step2: Take off the 14 rews on the teblet: Step3: Disconnect the side key, main camera, front camera, speaker and FPCs connector. Rev. Page 10/41 9015B Level 2E Repair Document All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
  • Page 11 L2E Repair Document Communication Ltd. Step4: Pry up the PCBA with the plastic flake. Rev. Page 11/41 9015B Level 2E Repair Document All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
  • Page 12 L2E Repair Document Communication Ltd. Step 5: Remove MIC rubber, Antenna and sub board. Step6: Remove the main LCD with pry bar. Rev. Page 12/41 9015B Level 2E Repair Document All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
  • Page 13 L2E Repair Document Communication Ltd. Step 7 Disassemble complete. Note: All the components listed below are spare parts for L2. All the connectors could be disassembled by hot wind gun. (hot wind gun temperature: 330℃, Air Level: 2~3, Height: around 10mm, Time: less than 60s) Please use high temperature protect film to protect surrounding elements when using hot wind gun.
  • Page 14 L2E Repair Document Communication Ltd. Rev. Page 14/41 9015B Level 2E Repair Document All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.

  • Page 15: Disassembly Notice

    L2E Repair Document Communication Ltd. 5.4 Disassembly Notice: 1). Receiver is easily to be damaged during disassembly process. Thus please do not disassemble receiver unless it is necessary. 2). About battery disassemble notice:  The battery can’t be reused when you disassemble it. ...

  • Page 16: Disassembly Process Evaluation

    L2E Repair Document Communication Ltd. 5.6 Disassembly process evaluation We list the Pixi4-7 3G parts disassembly time, technique levels and disassembly methods as below, for technique levels, Class 1 signifies easy to disassembly, Class 2 signifies normal to disassembly and Class 3 signifies hard to disassembly.
  • Page 17 L2E Repair Document Communication Ltd. Rev. Page 17/41 9015B Level 2E Repair Document All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.

  • Page 18: Level 2 Repair

    L2E Repair Document Communication Ltd. 7 Level 2 repair This chapter describes the Level 2 repair that can be done without any diagnostic equipment.  Charging failure Rev. Page 18/41 9015B Level 2E Repair Document All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
  • Page 19 L2E Repair Document Communication Ltd. Charging failure Check whether the voltage of the battery is 0V and Charge for 15 Replace battery minutes, check whether battery is good. r e p l a c e b a t t e r y C h e c k w h e t h e r b a t t e r y connector connector is good...
  • Page 20 L2E Repair Document Communication Ltd. Display failure Check whether the connection Reassemble LCD b e t w e e n LCD a n d LCD connector is good Reweld or replace LCD Check whether LCD connector is connector normal C h e c k w h e t h e r LCD i s Change LCD n o r m a l （...
  • Page 21 L2E Repair Document Communication Ltd. Touch function failure Check whether the connection Reassemble TP between TP and TP connector is good C h e c k w h e t h e r T P i s Change FURFRONT n o r m a l ( i n t e r c h a n g e CASING&TP method) Reweld or replace TP...
  • Page 22 L2E Repair Document Communication Ltd. S I M c a r d c a n ’ t b e recognized Re-assemble or change Check whether the SIM card is SIM card good C h e c k w h e t h e r S I M c a r d Re-weld or change SIM connector is good card connector...
  • Page 23 L2E Repair Document Communication Ltd. T F c a r d c a n ’ t b e recognized Check whether the TF card is Change TF card good C h e c k w h e t h e r t h e T F c a r d connector is good Change TF card connector and see if problem can be solved...
  • Page 24 L2E Repair Document Communication Ltd. Main camera function failure Check whether the connection Reassemble main camera between main camera and Main camera connector is good Check whether main camera is Replace main camera normal C h e c k w h e t h e r M a i n c a m e r a Reweld or replace Main connector is normal camera connector...
  • Page 25 L2E Repair Document Communication Ltd.  Sub camera function failure Sub camera function failure Check whether the connection Reassemble sub camera between sub camera and sub camera connector is good Check whether sub camera is Replace sub camera normal C h e c k w h e t h e r s u b c a m e r a R e w e l d o r r e p l a c e s u b connector is normal camera connector...

  • Page 26: L2 Enhance Repair

    L2E Repair Document Communication Ltd. Power on failure Charge for 15 minutes, check whether can power on Replace it with a new Check whether battery status is good battery Check whether power key R e w e l d o r R e p l a c e connector is damaged power key connector Replace PCBA...

  • Page 27: Position Of L2 Enhance Components On Pcba

    L2E Repair Document Communication Ltd. Interchange method means using a new component to test the function in order to verify whether the old component is defected. Please use hot wind gun to re-weld or disassemble/assemble the component mentioned afterwards. (hot wind gun temperature: 330℃, Air Level: 2~3, Height: around 10mm, Time: less than 60s) Before re-welding or disassembling/assembling the component, DO remember to paste high temperature adhesive tape on the components which are close to it, in order to avoid damaging of these components.

  • Page 28: Trouble Shooting For Common Failures

    L2E Repair Document Communication Ltd. U603 VR625 Touch IC Transient Voltage No touch function Suppressors No USB U503 LNA for GPS/GNSS No GPS signal U601 Triaxis Acceleration Sensor U201 Gravity control PMU Chipset Can’t power on/charge D202 L201/L202 Zener Diode L207 Power Inductor Can’t power on...
  • Page 29 L2E Repair Document Communication Ltd. C h e c k w h e t h e r t h e connection between LCD Reassemble LCD and J125 is good Check whether LCD is Change LCD n o r m a l （ i n t e r c h a n g e method）...
  • Page 30 L2E Repair Document Communication Ltd. 8.3.2 Power on failure R e a s s e m b l e o r Check whether side key replace side key is good R e w e l d o r r e p l a c e C h e c k w h e t h e r s i d e side key connector key connector...
  • Page 31 L2E Repair Document Communication Ltd. 8.3.3 TP function failure Reassemble TP Check whether the connection connector between TP connector is good Change Check whether TP is normal （interchange method） Reweld or replace C h e c k w h e t h e r U 6 0 3 i s U603 normal Replace Main PCBA...
  • Page 32 L2E Repair Document Communication Ltd. 8.3.4 No sound Reassemble or replace Check whether side key is side key good R e w e l d o r r e p l a c e Check whether J753/J754 J753/J754 is good R e w e l d o r r e p l a c e C h e c k w h e t h e r...
  • Page 33 L2E Repair Document Communication Ltd. 8.3.5 SIM card can’t be recognized Check whether the SIM card is Reassemble SIM card well inserted Reweld or replaceSIM Check whether SIM connector connector is normal Replace main PCBA 8.3.6 SD card can’t be recognized Check whether the SD card is Reassemble SD card well inserted...
  • Page 34 L2E Repair Document Communication Ltd. 8.3.7 Main camera function failure Check whether the connection R e a s s e m b l e m a i n between main camera and J701 camera is good Check whether main camera Change main camera is normal（interchange method）...
  • Page 35 L2E Repair Document Communication Ltd. 8.3.8 Front camera function failure Check whether the connection R e a s s e m b l e f r o n t between front camera and J702 camera is good Check whether front camera Change front camera is normal（interchange method）...
  • Page 36 L2E Repair Document Communication Ltd. 8.3.9 Charging failure Check whether charging Check whether USB cable Replace USB cable indicator displays OK is normal Replace new battery Check whether battery is and check the charge normal (such as volt etc.) function etc. Check whether USB Reweld or replace connector is normal...
  • Page 37 L2E Repair Document Communication Ltd. 8.3.11 Headset failure Check whether headset Replace headset is normal（interchange method） Check whether audio Jack Reweld or replace is normal audio Jack Replace main PCBA 8.3.13 G-sensor defect C h e c k w h e t h e r U 6 0 1 i s Reweld or replace normal U601...

  • Page 38: L2 Enhance Spare Part List

    L2E Repair Document Communication Ltd. 8.3.15 FM defect C h e c k w h e t h e r U 5 0 1 i s Reweld or replace normal U501 Replace main PCBA 8.4 L2 enhance spare part list Below table lists 9015B L2E spare parts, which is just for reference.
  • Page 39 L2E Repair Document Communication Ltd. Rev. Page 39/41 9015B Level 2E Repair Document All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.

  • Page 40: Pcba Exchange

    L2E Repair Document Communication Ltd. 9 PCBA exchange If Level 2E repair does not solve the failure, it is mandatory to change the PCBA and follow the process as below. Collect the PCBA (without accessories, LCD and camera). MIC should be enclosed when you exchange the PCBA.

  • Page 41: Functional Test

    Open “Calculator” application, and input “0x0-0+=” to start the MMI test or using Smart Diagnosis Tool to do the test. If you have any question or problem, please feel free to contact us Thanks for your cooperation. TCL Communication Ltd. Global Customer Service TS Dept. Jun. 7th, 2016 Rev.
