L2E Repair Document
Communication Ltd.
Pixi4-3.5 3G
4017A_D_E_F_X_S
Note: this manual is non-contractual and TCL Communication Ltd. can modify it without prior
notice on the characteristics of described equipments.
Rev.
Page
1.0
1/54
4017A_D_E_F_X_S Level 2 enhance Repair Document
All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
