Directions for use

Attaching the Tubing and Chamber

1. Connect the tubing to the chamber.
Match the black connector to the black
return port on the side of the chamber.
Match the blue connector to the blue
irrigation port on the lower side of the
chamber.
2. To attach the chamber to the faucet, pull
down the white plastic ring on the top of the
chamber, and then insert the chamber over
the snap aerator on the faucet. When the
chamber is positioned, release the white
plastic ring. The chamber is now secure.

Attaching an Ear Tip

1. Line up the grooves on the side of the ear
tip with the corresponding indentations
on the handle interface. Verify that you
are attaching the ear tip with the tab
facing upwards.
2. Press firmly on the ear tip until it is flush
against the handle interface. You will feel
a slight snap when the ear tip is in place.
