Summary of Contents for Welch Allyn 29350
- Page 1 Ear Wash System 29350 Operating Instruction Manual...
-
Page 3: Table Of Contents
Unpacking and Verifying Contents ....3 Diagram of the Welch Allyn Ear Wash System ..4 Faucet Aerator Installation ....5 Chamber Aerator Installation . -
Page 5: Introduction
Introduction Thank you for purchasing the Welch Allyn Ear Wash System. The Welch Allyn Ear Wash System provides a safe and effective way to remove cerumen from patients of all ages. This method of irrigation is much cleaner and safer than other irrigation methods currently on the market. -
Page 6: Warnings And Symbols
93/42/EEC Medical Device Directive Authorized European Representative Address: European Regulatory Manager Welch Allyn, Ltd. County Meath, Republic of Ireland Telephone: 353-46-67700 Fax: 353-46-27128 Only a licensed health care professional or a properly trained per- son under the direction of such a professional should perform the irrigation procedure. -
Page 7: Getting Started
Complete and return the warranty registration card. It validates the war- ranty and allows Welch Allyn to send announcements of product enhancements. When you unpack your new Welch Allyn Ear Wash System, verify that the following items are included: •... -
Page 8: Diagram Of The Welch Allyn Ear Wash System
Use the figure shown to familiarize yourself with the features of the Welch Allyn Ear Wash System. Diagram of the Welch Allyn Ear Wash System Snap Aerator Water Flow Actuator Snap Connector with white ring... -
Page 9: Faucet Aerator Installation
/ minute. If you suspect the line pressure or flow rate is greater, have it tested prior to use of the Ear Wash System or contact Welch Allyn Technical Service Department. 1. Remove your current aerator from your faucet, including any original washers. -
Page 10: Chamber Aerator Installation
Chamber Aerator Installation The chamber aerator is an optional attachment that is necessary if you are experiencing a significant amount of water splash around your sink. 1. Find the notch located on the top of the chamber aerator and line it up with the blue irrigation port on the chamber. -
Page 11: Using The Ear Wash System
Using the Ear Wash System Steps for Irrigation It is essential to follow the technique described in this section for using the Ear Wash System to minimize patient discomfort and avoid the risk of perforating the tympanic membrane. The factors determining the risk of perforating the tympanic membrane while irrigating the ear canal are the water pressure at the point of dis- charge and whether the discharged flow of water directly impinges on the tympanic membrane. -
Page 12: Attaching The Tubing And Chamber
Attaching the Tubing and Chamber 1. Connect the tubing to the chamber. Match the black connector to the black return port on the side of the chamber. Match the blue connector to the blue irri- gation port on the lower side of the chamber. -
Page 13: Irrigation
Irrigation 1. Initially, you may cover the patient with a cloth drape to eliminate splashing onto his or her clothes. Once the technique of sealing the ear canal is mastered, this is not necessary. 2. Begin to run water through the unit by turning the hot and cold water on full power. - Page 14 5. It is important to aim the stream of water away from the longitu- dal axis of the ear canal and toward the ear canal walls by tilting and rotating the handle during the irrigation. Flood the ear with water. The suction return system will return the discharge away from the ear.
-
Page 15: Disassembly
If the application of non-sterile tap water in a patient’s ear is a con- cern, administer a few drops of the following solutions as a preven- tative measure: • 70% Isopropyl Alcohol • Hydrogen Peroxide • Solution of 1 part Vinegar/1 part Isopropyl Alcohol NOTE: Discoloration or staining of the tubing can occur over time due to local water conditions and/or introduction of other ear clean- ing solutions. -
Page 16: Maintenance
Maintenance Cleaning and Disinfecting the System Clean or Disinfect Ear Wash System daily. High Level Disinfect each time the unit is used on a patient with compromised skin. Cleaning the unit eliminates any debris and reduces the number of micro- organisms in the tubing. - Page 17 To High Level Disinfect the Unit • Prepare at least 2 cups of .55% Ortho-Phthalaldehyde solution (Welch Allyn recommends the use of Cidex OPA). • Pour at least 2 cups of the solution into the top opening of the coupler.
-
Page 18: Troubleshooting
Troubleshooting If your Welch Allyn Ear Wash System is experiencing problems, consult the following table to find the symptom and the likely cause and the solu- tion. If the information in this table does not describe or solve the prob-... - Page 19 125mL of measured water, replace the tip and repeat. If the results are the same, con- tact your Welch Allyn Technical Service Department. Patient has very hard Apply ear drops for about 5 - 10 ear wax.
- Page 20 / 20 seconds, either add regu- lation to the faucet or move to a faucet with adquate water pres- sure and flow. Otherwise, con- tact your Welch Allyn Technical Service Department. Sensor not turning The sensor is defec- Replace handle/hose assembly.
- Page 21 1. If suction is too low, replace the ear tip. If suction does not improve go to step 2. 2. Remove ear tip and place handle interface into water. If suction improves replace handle/hose assembly. If suction does not improve go to step 3.
-
Page 22: Types Of Cerumen
Types of Cerumen Cerumen is the natural by-product of the ear canal. It lubricates the skin lining in the ear canal, acts as a water repellent, and entraps dust, hair fol- licles, and foreign bodies. Cerumen can take many different forms which affect the process and time to remove. -
Page 23: Anatomy And Physiology
Anatomy And Physiology • Cerumen is produced in the outer third of the ear canal and natu- rally moves to the outer ear as new tissue grows from the area around the tympanic membrane. • Normal cerumen routinely becomes a medical issue when it impedes the physicians ability to visualize the tympanic mem- brane. -
Page 24: Warranty And Service Information
Warranty and Service Information Warranty Welch Allyn, Inc. warrants the Ear Wash System to be free of original defects in material and workmanship and to perform in accordance with manufacturer’s specifications for a period of one year from the date of purchase. -
Page 25: Technical Service Department
For customers in North America, please return instruments requiring ser- vice to Welch Allyn or an authorized Welch Allyn Service Representative. Please call the Technical Service Department for a Return Authorization Number prior to shipping the Ear Wash System back to Welch Allyn for repair. United States: Canada: Welch Allyn, Inc. -
Page 26: Replacement Parts And Accessories
Replacement Parts and Accessories Ordering Information To order replacement parts or accessories, contact your Welch Allyn Ser- vice Representative or call the Welch Allyn Customer Service Depart- ment in Skaneateles Falls, NY (USA) directly at: 1-800-535-6663 Monday through Friday, 8:00AM to 8:00 PM EST... -
Page 27: Specifications
Specifications General Specifications The specifications common to all of the major components of Welch Allyn Ear Wash System are listed the following table. Operating Temperature: 50° - +104° F (10° - +40° C) Storage Temperature: -40° - +120° F (-40° - +49° C) Flow Rate from Ear Tip: 125 mL (0.0264 gal) of water per 20 seconds at operating pressure. - Page 28 Welch Allyn, Inc. 4341 State Street Road PO Box 220 Skaneateles Falls, NY 13153-0220 Tel: (315) 685-4560 1 (800) 535-6663 Printed in the U.S.A. Part No. 293044-1 Rev. F...
