4341 State Street Road
Skaneateles Falls, NY 13153 USA
Phone: (800) 535-6663 (US Only) or (315) 685-4560 • Fax: (315) 685-3361
www.welchallyn.com
No. 78600 (Series 58600 Vaginal Specula)
This illuminator is used in conjunction with 58600 and 58601 Disposable
Vaginal Specula, Vaginal Speculum Light Handle (78800), and Transformer
(73410)
To prepare for use:
1. Place illuminator on light handle.
2. Place illuminator and light handle into slot on 58600/58601 vaginal speculum
handle.
3. Slide illuminator assembly up until it locks into place.
4. Plug in transformer.
EXPENDABLE ILLUMINATOR
Mat'l No. 718532 Rev. A
4341 State Street Road
Skaneateles Falls, NY 13153 USA
Phone: (800) 535-6663 (US Only) or (315) 685-4560 • Fax: (315) 685-3361
www.welchallyn.com
No. 78600 (Series 58600 Vaginal Specula)
This illuminator is used in conjunction with 58600 and 58601 Disposable
Vaginal Specula, Vaginal Speculum Light Handle (78800), and Transformer
(73410)
To prepare for use:
1. Place illuminator on light handle.
2. Place illuminator and light handle into slot on 58600/58601 vaginal speculum
handle.
3. Slide illuminator assembly up until it locks into place.
4. Plug in transformer.
EXPENDABLE ILLUMINATOR
Mat'l No. 718532 Rev. A
