Read with Input Register / Status Function enabled
Data in reading:
Type
Input Register
Input Register
Input Register
Data in writing:
Type
Holding Register
Holding Register
Holding Register
Note:
The data can be read/written as single bits too using Input/Coil Status (Function 02 and Functions 01/05/15).
ADFweb.com S.r.l.
Address Function
0
1
2
.
.
.
Address Function
0
W: 06/16
1
W: 06/16
2
W: 06/16
.
.
.
Document code: MN67934_ENG
Description
Input Bytes 0-1 of internal array
04
Input Bytes 2-3 of internal array
04
Input Bytes 4-5 of internal array
04
Description
R: 03
Output Bytes 0-1 of internal array
R: 03
Output Bytes 2-3 of internal array
R: 03
Output Bytes 4-5 of internal array
