Speed and current curves - 12V motor
The values below are typical values and made with a stable power supply and an ambient temperature of 20˚C.
LA33 12V - current vs thrust
12,00
15mm pitch/B
10,00
20mm pitch
8,00
6,00
4,00
2,00
0,00
0 1000
LA33 12V - speed vs thrust
40
35
30
25
20
15
9mm pitch
10
5
0
0 1000
9mm pitch
2000 3000 4000
Thrust [N]
20mm pitch
15mm pitch/B
15mm pitch/A
2000 3000
Thrust [N]
